场效应晶体管（FETs）、MOSFETs
| 制造商 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部重置
应用所有
结果:
| 图片 | 型号 | 库存 | 价格 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SPP07N65C3XKSA1LOW POWER_LEGACY Infineon Technologies |
0 | - |
|
规格书 |
CoolMOS™ | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 650 V | 7.3A (Tc) | 10V | 600mOhm @ 4.6A, 10V | 3.9V @ 350µA | 27 nC @ 10 V | ±20V | 790 pF @ 25 V | - | 83W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO220-3-1 |
|
|
SPP11N60S5XKSA1LOW POWER_LEGACY Infineon Technologies |
0 | - |
|
规格书 |
CoolMOS™ | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 11A (Tc) | 10V | 380mOhm @ 7A, 10V | 5.5V @ 500µA | 54 nC @ 10 V | ±20V | 1460 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO220-3-1 |
|
BSC020N03LSGATMA2LV POWER MOS Infineon Technologies |
0 | - |
|
规格书 |
* | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
IPB50N12S3L15ATMA1MOSFET N-CHANNEL_100+ Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 120 V | 50A (Tc) | 4.5V, 10V | 15.7mOhm @ 50A, 10V | 2.4V @ 60µA | 57 nC @ 10 V | ±20V | 4180 pF @ 25 V | - | 100W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PG-TO263-3-2 |
|
|
IPB70N12S3L12ATMA1MOSFET N-CHANNEL_100+ Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ T | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 120 V | 70A (Tc) | 4.5V, 10V | 12.1mOhm @ 70A, 10V | 2.4V @ 83µA | 77 nC @ 10 V | ±20V | 5550 pF @ 25 V | - | 125W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PG-TO263-3-2 |
|
IPD70N12S3L12ATMA1MOSFET N-CHANNEL_100+ Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 120 V | 70A (Tc) | 4.5V, 10V | 11.5mOhm @ 70A, 10V | 2.4V @ 83µA | 77 nC @ 10 V | ±20V | 5550 pF @ 25 V | - | 125W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PG-TO252-3-11 |
|
|
IPC302N15N3X7SA1MV POWER MOS Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ 3 | Die | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | - | 10V | 100mOhm @ 2A, 10V | 4V @ 270µA | - | - | - | - | - | - | - | - | Surface Mount | Die |
|
|
IPT043N15N5ATMA1MV POWER MOS Infineon Technologies |
0 | - |
|
规格书 |
* | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
BSP612PH6327XTSA1SMALL SIGNAL+P-CH Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ | - | Tape & Reel (TR) | Obsolete | - | - | - | 3A (Ta) | - | - | - | - | - | - | - | - | - | Automotive | AEC-Q101 | - | - |
|
IPS040N03LGAKMA1MOSFET N-CH 30V 90A TO251-3 Infineon Technologies |
0 | - |
|
规格书 |
OptiMOS™ | TO-251-3 Stub Leads, IPAK | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 90A (Tc) | 4.5V, 10V | 4mOhm @ 30A, 10V | 2.2V @ 250µA | 38 nC @ 10 V | - | 3900 pF @ 15 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | PG-TO251-3-11 |
