固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82412A3820JFIXED IND 82NH 430MA 270MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 82 nH | ±5% | 430 mA | - | Unshielded | 270mOhm Max | 60 @ 500MHz | 1.1GHz | AEC-Q200 | -55°C ~ 125°C | 10 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.075" (1.90mm) |
|
|
B82412A3821JFIXED IND 820NH 150MA 2 OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 820 nH | ±5% | 150 mA | - | Unshielded | 2Ohm Max | 23 @ 50MHz | 380MHz | AEC-Q200 | -55°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.075" (1.90mm) |
|
|
B82498B1182J000SMT-INDUCTOR 0805 1800 NH 5% EPCOS - TDK Electronics |
0 |
|
- |
B82498B | 0805 (2012 Metric) | Tape & Reel (TR) | Last Time Buy | Wirewound | Ferrite | 1.8 µH | ±5% | 190 mA | - | Unshielded | 850mOhm Max | 20 @ 7.96MHz | 250MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Surface Mount | 0805 | 0.087" L x 0.055" W (2.20mm x 1.40mm) | 0.057" (1.45mm) |
|
|
B82498B1272J000SMT-INDUCTOR 0805 2700 NH 5% EPCOS - TDK Electronics |
0 |
|
- |
B82498B | 0805 (2012 Metric) | Tape & Reel (TR) | Last Time Buy | Wirewound | Ferrite | 2.7 µH | ±5% | 120 mA | - | Unshielded | 2Ohm Max | 20 @ 7.96MHz | 200MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Surface Mount | 0805 | 0.087" L x 0.055" W (2.20mm x 1.40mm) | 0.057" (1.45mm) |
|
|
B82498B1392J000SMT-INDUCTOR 0805 3900 NH 5% EPCOS - TDK Electronics |
0 |
|
- |
B82498B1 | 0805 (2012 Metric) | Tape & Reel (TR) | Last Time Buy | Wirewound | Ceramic, Ferrite | 3.9 µH | ±5% | 95 mA | - | Unshielded | 3.6Ohm Max | 20 @ 7.96MHz | 150MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Surface Mount | 0805 | 0.087" L x 0.055" W (2.20mm x 1.40mm) | 0.057" (1.45mm) |
|
|
B82498B1152J000SMT-INDUCTOR 0805 1500 NH 5% EPCOS - TDK Electronics |
0 |
|
- |
B82498B | 0805 (2012 Metric) | Tape & Reel (TR) | Last Time Buy | Wirewound | Ferrite | 1.5 µH | ±5% | 200 mA | - | Unshielded | 750mOhm Max | 20 @ 7.96MHz | 250MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Surface Mount | 0805 | 0.087" L x 0.055" W (2.20mm x 1.40mm) | 0.057" (1.45mm) |
|
|
B82498B1332J000SMT-INDUCTOR 0805 3300 NH 5% EPCOS - TDK Electronics |
0 |
|
- |
B82498B | 0805 (2012 Metric) | Tape & Reel (TR) | Last Time Buy | Wirewound | Ferrite | 3.3 µH | ±5% | 100 mA | - | Unshielded | 3.3Ohm Max | 20 @ 7.96MHz | 200MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Surface Mount | 0805 | 0.087" L x 0.055" W (2.20mm x 1.40mm) | 0.057" (1.45mm) |
|
B82432C1104J000FIXED IND 100UH 145MA 4.7OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±5% | 145 mA | - | Unshielded | 4.7Ohm Max | 30 @ 796kHz | 8MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
B82432C1124J000FIXED IND 120UH 140MA 5.2OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 120 µH | ±5% | 140 mA | - | Unshielded | 5.2Ohm Max | 30 @ 796kHz | 8MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
|
|
B82432C1154J000FIXED IND 150UH 130MA 6.1OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±5% | 130 mA | - | Unshielded | 6.1Ohm Max | 30 @ 796kHz | 7MHz | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 1812 (4532 Metric) | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.134" (3.40mm) |
