固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ASPI-0602S-330M-TFIXED IND 33UH 970MA 165MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 970 mA | - | Shielded | 165mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-390M-TFIXED IND 39UH 860MA 210MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 39 µH | ±20% | 860 mA | - | Shielded | 210mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-470M-TFIXED IND 47UH 800MA 238MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 800 mA | - | Shielded | 238mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-560M-TFIXED IND 56UH 730MA 277MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 56 µH | ±20% | 730 mA | - | Shielded | 277mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-680M-TFIXED IND 68UH 650MA 304MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±20% | 650 mA | - | Shielded | 304mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-820M-TFIXED IND 82UH 600MA 390MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 82 µH | ±20% | 600 mA | - | Shielded | 390mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
ASPI-0602S-101M-TFIXED IND 100UH 540MA 535MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPI-0602S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±20% | 540 mA | - | Shielded | 535mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
ASPI-8040S-6R8N-TFIXED IND 6.8UH 3.6A 24 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-8040S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 3.6 A | 4.55A | Shielded | 24mOhm | - | 20MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
ASPI-0520LR-5R6M-T2FIXED IND 5.6UH 3.5A 75 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0520LR | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 5.6 µH | ±20% | 3.5 A | 3.3A | Unshielded | 75mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.220" L x 0.205" W (5.60mm x 5.20mm) | 0.083" (2.10mm) |
|
ASPI-0530LR-2R2M-T2FIXED IND 2.2UH 7A 26 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-0530LR | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 2.2 µH | ±20% | 7 A | 5.5A | Shielded | 26mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.220" L x 0.205" W (5.60mm x 5.20mm) | 0.118" (3.00mm) |
