固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
84223CFIXED IND 22UH 600MA 600MOHM SMD Murata Power Solutions Inc. |
1,342 |
|
规格书 |
8400 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 µH | ±10% | 600 mA | - | Unshielded | 600mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.177" L x 0.130" W (4.50mm x 3.30mm) | 0.114" (2.90mm) |
|
24470CFIXED IND 47UH 720MA 370MOHM SMD Murata Power Solutions Inc. |
1,566 |
|
规格书 |
2400 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 47 µH | - | 720 mA | - | Unshielded | 370mOhm Max | - | 10.9MHz | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.228" L x 0.205" W (5.80mm x 5.20mm) | 0.177" (4.50mm) |
|
13R225CFIXED IND 2.2MH 240MA 4.5 OHM TH Murata Power Solutions Inc. |
12,423 |
|
规格书 |
1300R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 2.2 mH | ±10% | 240 mA | - | Unshielded | 4.5Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.374" Dia (9.50mm) | 0.531" (13.50mm) |
|
|
13R104CFIXED IND 100UH 1A 240 MOHM TH Murata Power Solutions Inc. |
3,141 |
|
规格书 |
1300R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 100 µH | ±10% | 1 A | - | Unshielded | 240mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.374" Dia (9.50mm) | 0.531" (13.50mm) |
|
|
13R106CFIXED IND 10MH 85MA 23.8 OHM TH Murata Power Solutions Inc. |
2,932 |
|
规格书 |
1300R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 10 mH | ±10% | 85 mA | - | Unshielded | 23.8Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.374" Dia (9.50mm) | 0.531" (13.50mm) |
|
22R105CFIXED IND 1MH 170MA 3.63 OHM TH Murata Power Solutions Inc. |
2,285 |
|
规格书 |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 1 mH | ±10% | 170 mA | - | Unshielded | 3.63Ohm Max | 120 @ 100kHz | 2.1MHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
|
|
22R224CFIXED IND 220UH 430MA 830MOHM TH Murata Power Solutions Inc. |
2,072 |
|
规格书 |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 220 µH | ±10% | 430 mA | - | Unshielded | 830mOhm Max | 100 @ 100kHz | 4.4MHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
|
|
22R223CFIXED IND 22UH 1.08A 90 MOHM TH Murata Power Solutions Inc. |
1,836 |
|
规格书 |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 22 µH | ±10% | 1.08 A | - | Unshielded | 90mOhm Max | 50 @ 500kHz | 17MHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
|
|
13R334CFIXED IND 330UH 580MA 640MOHM TH Murata Power Solutions Inc. |
1,517 |
|
规格书 |
1300R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 330 µH | ±10% | 580 mA | - | Unshielded | 640mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.374" Dia (9.50mm) | 0.531" (13.50mm) |
|
|
22R333CFIXED IND 33UH 900MA 140 MOHM TH Murata Power Solutions Inc. |
1,438 |
|
规格书 |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 33 µH | ±10% | 900 mA | - | Unshielded | 140mOhm Max | 50 @ 500kHz | 11.4MHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
