场效应晶体管（FETs）、MOSFETs
| 制造商 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部重置
应用所有
结果:
| 图片 | 型号 | 库存 | 价格 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HUFA75645S3SMOSFET N-CH 100V 75A D2PAK Fairchild Semiconductor |
1,228 | - |
|
规格书 |
UltraFET™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 75A (Tc) | 10V | 14mOhm @ 75A, 10V | 4V @ 250µA | 238 nC @ 20 V | ±20V | 3790 pF @ 25 V | - | 310W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
FQA9N90-F109POWER FIELD-EFFECT TRANSISTOR, 8 Fairchild Semiconductor |
398 | - |
|
规格书 |
QFET® | TO-3P-3, SC-65-3 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 900 V | 8.6A (Tc) | 10V | 1.3Ohm @ 4.3A, 10V | 5V @ 250µA | 72 nC @ 10 V | ±30V | 2700 pF @ 25 V | - | 240W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-3PN |
|
FCP13N60NPOWER FIELD-EFFECT TRANSISTOR, 1 Fairchild Semiconductor |
2,341 | - |
|
规格书 |
SupreMOS™ | TO-220-3 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Tc) | 10V | 258mOhm @ 6.5A, 10V | 4V @ 250µA | 39.5 nC @ 10 V | ±30V | 1765 pF @ 100 V | - | 116W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
FDMS86152POWER FIELD-EFFECT TRANSISTOR, 1 Fairchild Semiconductor |
479 | - |
|
规格书 |
PowerTrench® | 8-PowerTDFN | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 14A (Ta), 45A (Tc) | 6V, 10V | 6mOhm @ 14A, 10V | 4V @ 250µA | 50 nC @ 10 V | ±20V | 3370 pF @ 50 V | - | 2.7W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-PQFN (5x6) |
|
FDBL86563-F085MOSFET N-CH 60V 240A 8HPSOF Fairchild Semiconductor |
22,000 | - |
|
规格书 |
PowerTrench® | 8-PowerSFN | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 240A (Tc) | 10V | 1.5mOhm @ 80A, 10V | 4V @ 250µA | 169 nC @ 10 V | ±20V | 10300 pF @ 30 V | - | 357W (Tj) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-HPSOF |
|
FQAF16N50POWER FIELD-EFFECT TRANSISTOR, 1 Fairchild Semiconductor |
7,560 | - |
|
规格书 |
QFET® | TO-3P-3 Full Pack | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 11.3A (Tc) | 10V | 320mOhm @ 5.65A, 10V | 5V @ 250µA | 75 nC @ 10 V | ±30V | 3000 pF @ 25 V | - | 110W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
FDI038AN06A0MOSFET N-CH 60V 17A/80A I2PAK Fairchild Semiconductor |
1,432 | - |
|
规格书 |
PowerTrench® | TO-262-3 Long Leads, I2PAK, TO-262AA | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 17A (Ta), 80A (Tc) | 6V, 10V | 3.8mOhm @ 80A, 10V | 4V @ 250µA | 124 nC @ 10 V | ±20V | 6400 pF @ 25 V | - | 310W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-262 (I2PAK) |
|
FCH170N60MOSFET N-CH 600V 22A TO247-3 Fairchild Semiconductor |
11,671 | - |
|
规格书 |
SuperFET® II | TO-247-3 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 22A (Tc) | 10V | 170mOhm @ 11A, 10V | 3.5V @ 250µA | 55 nC @ 10 V | ±20V | 2860 pF @ 380 V | - | 227W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247 |
|
|
FCP104N60POWER FIELD-EFFECT TRANSISTOR, 3 Fairchild Semiconductor |
129 | - |
|
规格书 |
SuperFET® II | TO-220-3 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 37A (Tc) | 10V | 104mOhm @ 18.5A, 10V | 3.5V @ 250µA | 82 nC @ 10 V | ±20V | 4165 pF @ 380 V | - | 357W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
FCPF290N80POWER FIELD-EFFECT TRANSISTOR, 1 Fairchild Semiconductor |
7,634 | - |
|
规格书 |
PowerTrench® | TO-220-3 Full Pack | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 17A (Tc) | 10V | 290mOhm @ 8.5A, 10V | 4.5V @ 1.7mA | 75 nC @ 10 V | ±20V | 3205 pF @ 100 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220F |
