上传BOM
固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82442T1394J000SMT-INDUCTOR 2220-T 390 UH 10% EPCOS - TDK Electronics |
0 |
|
规格书 |
B82442T1 | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Wirewound | Ferrite | 390 µH | ±5% | 260 mA | 520mA | Unshielded | 3.7Ohm Max | 20 @ 796kHz | 3MHz | AEC-Q200 | -55°C ~ 150°C | 796 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
|
B82442T1474J000SMT-INDUCTOR 2220-T 470 UH 10%, EPCOS - TDK Electronics |
0 |
|
规格书 |
B82442T1 | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Wirewound | Ferrite | 470 µH | ±5% | 240 mA | 460mA | Unshielded | 4.73Ohm Max | 20 @ 796kHz | 2.6MHz | AEC-Q200 | -55°C ~ 150°C | 796 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
B82442T1274K000FIXED IND 270UH 290MA 2.95OHM SM EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 270 µH | ±10% | 290 mA | 560mA | Unshielded | 2.95Ohm Max | 20 @ 796kHz | 3.5MHz | AEC-Q200 | -55°C ~ 150°C | 796 kHz | - | Surface Mount | - | 0.220" L x 0.197" W (5.60mm x 5.00mm) | 0.209" (5.30mm) |
|
B82471A1153M000FIXED IND 15UH 1.3A 140 MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
B82471A1 | Nonstandard | Tape & Reel (TR) | Not For New Designs | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 1.3 A | 1.45A | Unshielded | 140mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.220" W (6.10mm x 5.60mm) | 0.193" (4.90mm) |
|
|
B82471A1154K000FIXED IND 150UH 400MA 1.1OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
B82471A1 | Nonstandard | Tape & Reel (TR) | Not For New Designs | Drum Core, Wirewound | Ferrite | 150 µH | ±10% | 400 mA | 480mA | Unshielded | 1.1Ohm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.220" W (6.10mm x 5.60mm) | 0.193" (4.90mm) |
|
|
B82471A1683K000FIXED IND 68UH 610MA 460MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
B82471A1 | Nonstandard | Tape & Reel (TR) | Not For New Designs | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 610 mA | 700mA | Unshielded | 460mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.240" L x 0.220" W (6.10mm x 5.60mm) | 0.193" (4.90mm) |
|
B82131A5202M000FIXED IND 3UH 2A 90 MOHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
B82131 | Axial | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Iron | 3 µH | ±20% | 2 A | - | Unshielded | 90mOhm | - | 113MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | - | 0.197" Dia x 0.591" L (5.00mm x 15.00mm) | - |
.jpg)
|
B82422A3180K100FIXED IND 18NH 640MA 120MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 18 nH | ±10% | 640 mA | - | Unshielded | 120mOhm Max | 30 @ 100MHz | 2.5GHz | AEC-Q200 | -55°C ~ 125°C | 10 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.083" (2.10mm) |
|
|
B82422A3390K100FIXED IND 39NH 530MA 180MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 39 nH | ±10% | 530 mA | - | Unshielded | 180mOhm Max | 25 @ 50MHz | 1.45GHz | AEC-Q200 | -55°C ~ 125°C | 10 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.083" (2.10mm) |
|
|
B82422A3391K100FIXED IND 390NH 190MA 1.4OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 390 nH | ±10% | 190 mA | - | Unshielded | 1.4Ohm Max | 22 @ 30MHz | 540MHz | AEC-Q200 | -55°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.083" (2.10mm) |
