固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82498F3820G000FIXED IND 82NH 500MA 190MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 82 nH | ±2% | 500 mA | - | Unshielded | 190mOhm Max | 60 @ 500MHz | 1.5GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.091" L x 0.067" W (2.30mm x 1.70mm) | 0.055" (1.40mm) |
|
|
B82498F3820G001FIXED IND 82NH 500MA 190MOHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 82 nH | ±2% | 500 mA | - | Unshielded | 190mOhm Max | 60 @ 500MHz | 1.5GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.091" L x 0.067" W (2.30mm x 1.70mm) | 0.055" (1.40mm) |
|
|
B82498F3821G001FIXED IND 820NH 180MA 1.9OHM SMD EPCOS - TDK Electronics |
0 |
|
规格书 |
SIMID | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 820 nH | ±2% | 180 mA | - | Unshielded | 1.9Ohm Max | 23 @ 50MHz | 300MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.091" L x 0.067" W (2.30mm x 1.70mm) | 0.055" (1.40mm) |
|
B82144B1824J000FIXED IND 820UH 310MA 3.7 OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 820 µH | ±5% | 310 mA | - | Unshielded | 3.7Ohm Max | 20 @ 796kHz | 2.4MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
|
B82145A1224J000FIXED IND 220UH 690MA 1.1 OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
HLBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±5% | 690 mA | - | Unshielded | 1.1Ohm Max | 30 @ 796kHz | 2.5MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.472" L (6.50mm x 12.00mm) | - |
|
B82144A2107J009HF CHOKE 100000 UH 5% EPCOS - TDK Electronics |
0 |
|
规格书 |
B82144A2 | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 100 mH | ±5% | 20 mA | - | Unshielded | 420Ohm Max | 30 @ 79.6kHz | 120kHz | - | -55°C ~ 125°C | 10 kHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144A2152K000HF CHOKE EPCOS - TDK Electronics |
0 |
|
规格书 |
B82144A2 | Axial | Tape & Reel (TR) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 2.1 A | - | Unshielded | 90mOhm Max | 40 @ 7.96MHz | 190MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82144A2152K009HF CHOKE EPCOS - TDK Electronics |
0 |
|
规格书 |
B82144A2 | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 2.1 A | - | Unshielded | 90mOhm Max | 40 @ 7.96MHz | 190MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | Axial | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
|
B82145A1154J000FIXED IND 150UH 770MA 900MOHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
HLBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±5% | 770 mA | - | Unshielded | 900mOhm Max | 40 @ 796kHz | 3MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.472" L (6.50mm x 12.00mm) | - |
|
|
B82145A1565J000FIXED IND 5.6MH TH EPCOS - TDK Electronics |
0 |
|
规格书 |
HLBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 5.6 mH | ±5% | - | - | Unshielded | - | - | - | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.472" L (6.50mm x 12.00mm) | - |
