固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82144A2336J000FIXED IND 33MH 35MA 150 OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 mH | ±5% | 35 mA | - | Unshielded | 150Ohm Max | 50 @ 79.6kHz | 220kHz | - | -55°C ~ 125°C | 10 kHz | - | Through Hole | - | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
B82144A2686J000FIXED IND 68MH 25MA 290 OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 mH | ±5% | 25 mA | - | Unshielded | 290Ohm Max | 40 @ 79.6kHz | 150kHz | - | -55°C ~ 125°C | 10 kHz | - | Through Hole | - | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) | - |
|
B82144F1155J000FIXED IND 1.5MH 230MA 6.4OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
B82144F1 | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.5 mH | ±5% | 230 mA | - | Unshielded | 6.4Ohm Max | 60 @ 252kHz | 1.9MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
B82144B1474J000FIXED IND 470UH 400MA 2.2 OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 470 µH | ±5% | 400 mA | - | Unshielded | 2.2Ohm Max | 30 @ 796kHz | 2.9MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
|
B82144F2103K9FIXED IND 10UH 2.45A 0.12OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 10 µH | ±10% | 2.45 A | 2.85A | Unshielded | 120mOhm Max | 40 @ 252kHz | 22MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F2123K9FIXED IND 12UH 2.4A 0.13OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 12 µH | ±10% | 2.4 A | 2.65A | Unshielded | 130mOhm Max | 40 @ 252kHz | 20MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F2152K9FIXED IND 1.5UH 4.1A 0.045OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 1.5 µH | ±10% | 4.1 A | 7.2A | Unshielded | 45mOhm Max | 60 @ 2.52MHz | 170MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F2153K9FIXED IND 15UH 2.3A 0.14OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 15 µH | ±10% | 2.3 A | 2.4A | Unshielded | 140mOhm Max | 50 @ 252kHz | 13MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F2182K9FIXED IND 1.8UH 3.75A 0.05OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 1.8 µH | ±10% | 3.75 A | 6.4A | Unshielded | 50mOhm Max | 60 @ 2.52MHz | 150MHz | - | -55°C ~ 125°C | 1 MHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
|
B82144F2183K9FIXED IND 18UH 2.2A 0.155OHM TH EPCOS - TDK Electronics |
0 |
|
规格书 |
LBC | Axial | Tape & Box (TB) | Active | Wirewound | Ferrite | 18 µH | ±10% | 2.2 A | 2.25A | Unshielded | 155mOhm Max | 50 @ 252kHz | 12MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
