固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XFHCL4-R33MFIXED IND 330NH 42A 1.2 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 330 nH | ±20% | 42 A | 80A | Shielded | 1.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-R10MFIXED IND 100NH 55A 0.6 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 100 nH | ±20% | 55 A | 80A | Shielded | 0.6mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-1R5MFIXED IND 1.5UH 23A 4.1 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 1.5 µH | ±20% | 23 A | 48A | Shielded | 4.1mOhm Max | - | - | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-R68MFIXED IND 680NH 34A 1.7 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 680 nH | ±20% | 34 A | 54A | Shielded | 1.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-5R6MFIXED IND 5.6UH 11A 17 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 5.6 µH | ±20% | 11 A | 22A | Shielded | 17mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-1R8MFIXED IND 1.8UH 19A 4.9 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 1.8 µH | ±20% | 19 A | 35A | Shielded | 4.9mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL19M-1R0MFIXED IND 1.0UH 8.5A 27 MOHM SMD XFMRS |
3,000 |
|
规格书 |
XFHCL19M | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 µH | ±20% | 5 A | 8.5A | Shielded | 27mOhm Max | 20 @ 100kHz | 64MHz | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.169" W (4.70mm x 4.30mm) | 0.079" (2.00mm) |
|
|
XFHCL19M-R22MFIXED IND 0.22UH 24A 7.3 MOHM SM XFMRS |
3,000 |
|
规格书 |
XFHCL19M | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 220 nH | ±20% | 11 A | 24A | Shielded | 7.3mOhm Max | 5 @ 100kHz | 120MHz | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.169" W (4.70mm x 4.30mm) | 0.079" (2.00mm) |
|
|
XFHCL19M-R33MFIXED IND 0.33UH 18A 8.6 MOHM SM XFMRS |
3,000 |
|
规格书 |
XFHCL19M | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 330 nH | ±20% | 10 A | 18A | Shielded | 8.6mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.169" W (4.70mm x 4.30mm) | 0.079" (2.00mm) |
|
|
XFHCL19M-1R2MFIXED IND 1.2UH 7.8A 30 MOHM SMD XFMRS |
3,000 |
|
规格书 |
XFHCL19M | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1.2 µH | ±20% | 4.8 A | 11A | Shielded | 27mOhm Max | 8 @ 100kHz | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.169" W (4.70mm x 4.30mm) | 0.079" (2.00mm) |
