固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
744758382AFIXED IND 8.2UH 320MA 2.6OHM SMD Würth Elektronik |
18 |
|
规格书 |
WE-RFH | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 8.2 µH | ±5% | 320 mA | - | Unshielded | 2.6Ohm Max | 20 @ 7.96MHz | 50MHz | - | -40°C ~ 85°C | 7.96 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.102" L x 0.083" W (2.60mm x 2.10mm) | 0.075" (1.90mm) |
|
|
744758410AFIXED IND 10UH 300MA 2.8 OHM SMD Würth Elektronik |
15 |
|
规格书 |
WE-RFH | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±5% | 300 mA | - | Unshielded | 2.8Ohm Max | 15 @ 2.52MHz | 40MHz | - | -40°C ~ 85°C | 2.52 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.102" L x 0.083" W (2.60mm x 2.10mm) | 0.075" (1.90mm) |
.jpg)
|
744760327AFIXED IND 2.7UH 100MA 3.5OHM SMD Würth Elektronik |
0 |
|
规格书 |
WE-RFI | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.7 µH | ±5% | 100 mA | - | Unshielded | 3.5Ohm Max | 15 @ 7.96MHz | 100MHz | - | -40°C ~ 85°C | 7.96 MHz | - | Surface Mount | 0805 | 0.090" L x 0.067" W (2.29mm x 1.70mm) | 0.058" (1.48mm) |
|
744764006FIXED IND 680NH 450MA 600MOHM SM Würth Elektronik |
0 |
|
规格书 |
WE-GF | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 680 nH | ±10% | 450 mA | - | Unshielded | 600mOhm Max | 30 @ 25.2MHz | 400MHz | - | -40°C ~ 105°C | 25.2 MHz | - | Surface Mount | 3225 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.094" (2.40mm) |
|
744766233FIXED IND 330UH 85MA 14 OHM SMD Würth Elektronik |
1 |
|
规格书 |
WE-GF | 1812 (4532 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±10% | 85 mA | - | Unshielded | 14Ohm Max | 40 @ 796kHz | 4.5MHz | - | -40°C ~ 105°C | 796 kHz | - | Surface Mount | 4532 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.142" (3.60mm) |
|
7440320027FIXED IND 2.7UH 600MA 180MOHM SM Würth Elektronik |
0 |
|
规格书 |
WE-LQ | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.7 µH | ±20% | 600 mA | 1.6A | Unshielded | 180mOhm Max | 20 @ 1MHz | 43MHz | - | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.091" (2.30mm) |
|
7447720010FIXED IND 1UH 6.9A 13.5 MOHM TH Würth Elektronik |
20 |
|
规格书 |
WE-TI | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 1 µH | ±30% | 6.9 A | 15A | Unshielded | 13.5mOhm Max | - | 195MHz | - | -40°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.307" Dia (7.80mm) | 0.394" (10.00mm) |
|
|
7447720681FIXED IND 680UH 520MA 1.37OHM TH Würth Elektronik |
0 |
|
规格书 |
WE-TI | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 680 µH | ±10% | 520 mA | 610mA | Unshielded | 1.37Ohm Max | - | 2.1MHz | - | -40°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.307" Dia (7.80mm) | 0.394" (10.00mm) |
|
7447720180FIXED IND 18UH 3.1A 47 MOHM TH Würth Elektronik |
0 |
|
规格书 |
WE-TI | Radial, Vertical Cylinder (Open) | Tray | Active | Drum Core, Wirewound | Ferrite | 18 µH | ±10% | 3.1 A | 3.5A | Unshielded | 47mOhm Max | - | 14.1MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.307" Dia (7.80mm) | 0.394" (10.00mm) |
|
7687480122WE-TI HV RADIAL LEADED WIRE WOUN Würth Elektronik |
13 |
|
规格书 |
WE-TI HV | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 1.2 mH | ±5% | 620 mA | 840mA | Unshielded | 1.4Ohm Max | - | 1.3MHz | - | -40°C ~ 125°C | 10 kHz | - | Through Hole | Radial, Vertical Cylinder | 0.413" Dia (10.50mm) | 0.571" (14.50mm) |
