固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SCEP104S-2R5FIXED IND 2.5UH 7.4A 21.8MOHM SM Signal Transformer |
0 |
|
规格书 |
SCEP104S | Nonstandard | Tape & Reel (TR) | Active | - | - | 2.5 µH | ±20% | 7.4 A | 11.8A | Shielded | 21.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.177" (4.50mm) |
|
|
SCEP104S-R22FIXED IND 220NH 23A 2.6 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP104S | Nonstandard | Tape & Reel (TR) | Active | - | - | 220 nH | ±30% | 23 A | 39.6A | Shielded | 2.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.177" (4.50mm) |
|
|
SCEP104S-R45FIXED IND 450NH 17A 3.7 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP104S | Nonstandard | Tape & Reel (TR) | Active | - | - | 450 nH | ±20% | 17 A | 27.6A | Shielded | 3.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.177" (4.50mm) |
|
|
SCEP104S-R80FIXED IND 800NH 14A 5.9 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP104S | Nonstandard | Tape & Reel (TR) | Active | - | - | 800 nH | ±20% | 14 A | 20.7A | Shielded | 5.9mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.177" (4.50mm) |
|
SCEP105H-1R2FIXED IND 1.2UH 11A 8 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1.2 µH | ±20% | 11 A | 21A | Shielded | 8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
SCEP105H-1R5FIXED IND 1.5UH 8.5A 10.5MOHM SM Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1.5 µH | ±20% | 8.5 A | 18A | Shielded | 10.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
SCEP105H-2R5FIXED IND 2.5UH 7.8A 18 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.5 µH | ±20% | 7.8 A | 14A | Shielded | 18mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
SCEP105H-3R0FIXED IND 3UH 7.2A 23.8 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 3 µH | ±20% | 7.2 A | 12.6A | Shielded | 23.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
SCEP105H-R15FIXED IND 150NH 20A 2.6 MOHM SMD Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 150 nH | ±30% | 20 A | 55A | Shielded | 2.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
SCEP105H-R30FIXED IND 300NH 18.8A 3.2MOHM SM Signal Transformer |
0 |
|
规格书 |
SCEP105H | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 300 nH | ±30% | 18.8 A | 40A | Shielded | 3.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
