固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SC312MF-180FIXED IND 18UH 440MA 1.16OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 18 µH | ±20% | 440 mA | 680mA | Shielded | 1.16Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-1R5FIXED IND 1.5UH 1.5A 104MOHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 1.5 µH | ±20% | 1.5 A | 2.5A | Shielded | 104mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-220FIXED IND 22UH 400MA 1.4 OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 22 µH | ±20% | 400 mA | 640mA | Shielded | 1.4Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-270FIXED IND 27UH 380MA 1.65OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 27 µH | ±20% | 380 mA | 600mA | Shielded | 1.65Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-2R2FIXED IND 2.2UH 1.2A 157MOHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 2.2 µH | ±20% | 1.2 A | 2A | Shielded | 157mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-330FIXED IND 33UH 330MA 2.4 OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 33 µH | ±20% | 330 mA | 570mA | Shielded | 2.4Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-3R3FIXED IND 3.3UH 980MA 210MOHM SM Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 3.3 µH | ±20% | 980 mA | 1.8A | Shielded | 210mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-470FIXED IND 47UH 250MA 3 OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 47 µH | ±20% | 250 mA | 440mA | Shielded | 3Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-4R7FIXED IND 4.7UH 840MA 318MOHM SM Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 4.7 µH | ±20% | 840 mA | 1.48A | Shielded | 318mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
|
|
SC312MF-560FIXED IND 56UH 230MA 3.6 OHM SMD Signal Transformer |
0 |
|
规格书 |
SC312MF | Nonstandard | Tape & Reel (TR) | Obsolete | Wirewound | - | 56 µH | ±20% | 230 mA | 420mA | Shielded | 3.6Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | 0.053" (1.35mm) |
