固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ASPIAIG-QLR5050-6R8M-TFIXED IND 6.8UH 6.4A 28.6MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-QLR5050 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 6.4 A | 6.6A | Shielded | 28.6mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPIAIG-QLR5050-5R6M-TFIXED IND 5.6UH 7.2A 24.2MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-QLR5050 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 7.2 A | 7.2A | Shielded | 24.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPIAIG-QLR5050-8R2M-TFIXED IND 8.2UH 6.1A 32.5MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-QLR5050 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 6.1 A | 6.1A | Shielded | 32.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
AIAP-01-561K-TFIXED IND 560UH 210MA 4.7 OHM TH Abracon LLC |
0 |
|
规格书 |
AIAP-01 | Axial | Tape & Reel (TR) | Active | Wirewound | - | 560 µH | ±10% | 210 mA | - | Unshielded | 4.7Ohm Max | - | 1.3MHz | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.130" Dia x 0.360" L (3.30mm x 9.14mm) | - |
|
ASPIAIG-S8050-1R0M-TFIXED IND 1UH 7.2A 10 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 1 µH | ±20% | 7.2 A | 16A | Shielded | 10mOhm | - | 99MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
|
|
ASPIAIG-S8050-1R5M-TFIXED IND 1.5UH 6.5A 12 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 1.5 µH | ±20% | 6.5 A | 13A | Shielded | 12mOhm | - | 79MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
|
|
ASPIAIG-S8050-2R2M-TFIXED IND 2.2UH 5.8A 14 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 2.2 µH | ±20% | 5.8 A | 11A | Shielded | 14mOhm | - | 59MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
|
|
ASPIAIG-S8050-8R2M-TFIXED IND 8.2UH 3.8A 35 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 8.2 µH | ±20% | 3.8 A | 5.6A | Shielded | 35mOhm | - | 18MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
|
|
ASPIAIG-S8050-150M-TFIXED IND 15UH 2.7A 61 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 15 µH | ±20% | 2.7 A | 4.5A | Shielded | 61mOhm | - | 13MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
|
|
ASPIAIG-S8050-220M-TFIXED IND 22UH 2.2A 88 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-S8050 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Nickel Zinc Ferrite (NiZn) | 22 µH | ±20% | 2.2 A | 3.5A | Shielded | 88mOhm | - | 9MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.205" (5.20mm) |
