固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ASPIAIG-F5020-R47M-TFIXED IND 470NH 14.1A 8.05 MOHM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-F | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 470 nH | ±20% | 14.1 A | 20A | Shielded | 8.05mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 5020 | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 0.083" (2.10mm) |
|
|
ASPIAIG-F5020-R68M-TFIXED IND 680NH 13.4A 10.2 MOHM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-F | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 680 nH | ±20% | 13.4 A | 14A | Shielded | 10.2mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 5020 | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 0.083" (2.10mm) |
|
|
ASPIAIG-F5020-R82M-TFIXED IND 820NH 12A 12.7 MOHM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-F | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 820 nH | ±20% | 12 A | 13A | Shielded | 12.7mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 5020 | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 0.083" (2.10mm) |
|
|
ASPI-104S-150N-TFIXED IND 15UH 3.6A 50 MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPI-104S | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±30% | 3.6 A | - | Shielded | 50mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.406" W (10.40mm x 10.30mm) | 0.157" (4.00mm) |
|
|
ASPI-5050LR-8R2M-TIND 8.2UH 6.1A 32.5M Abracon LLC |
0 |
|
规格书 |
ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 6.1 A | 6.1A | Shielded | 32.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-150M-TIND 15UH 4A 66.0M Abracon LLC |
0 |
|
规格书 |
ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 15 µH | ±20% | 4 A | 4.6A | Shielded | 66mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-5R6M-TIND 5.6UH 7.2A 24.2M Abracon LLC |
0 |
|
规格书 |
ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 7.2 A | 7.2A | Shielded | 24.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-6R8M-TIND 6.8UH 6.4A 28.6M Abracon LLC |
0 |
|
规格书 |
ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 6.4 A | 6.6A | Shielded | 28.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
ASPI-5050LR-220M-TIND 22UH 3.4A 99.7M Abracon LLC |
0 |
|
规格书 |
ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 22 µH | ±20% | 3.4 A | 4.1A | Shielded | 99.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
AISM-1812-R33M-TFIXED IND 330NH 605MA 300MOHM SM Abracon LLC |
0 |
|
规格书 |
AISM-1812 | 1812 (4532 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 nH | ±20% | 605 mA | - | Unshielded | 300mOhm Max | 40 @ 25.2MHz | 165MHz | - | -40°C ~ 85°C | 25.2 MHz | - | Surface Mount | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | 0.110" (2.80mm) |
