固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AIUR-07-180KFIXED IND 18UH 900MA 140 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 18 µH | ±10% | 900 mA | 1.1A | Unshielded | 140mOhm Max | 31 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-220KFIXED IND 22UH 810MA 160 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±10% | 810 mA | 1A | Unshielded | 160mOhm Max | 29 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-270KFIXED IND 27UH 740MA 190 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 27 µH | ±10% | 740 mA | 900mA | Unshielded | 190mOhm Max | 27 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-330KFIXED IND 33UH 680MA 250 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±10% | 680 mA | 800mA | Unshielded | 250mOhm Max | 37 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-390KFIXED IND 39UH 620MA 280 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 39 µH | ±10% | 620 mA | 500mA | Unshielded | 280mOhm Max | 37 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-470KFIXED IND 47UH 570MA 320 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±10% | 570 mA | 700mA | Unshielded | 320mOhm Max | 35 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-560KFIXED IND 56UH 510MA 370 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 56 µH | ±10% | 510 mA | 600mA | Unshielded | 370mOhm Max | 34 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-680KFIXED IND 68UH 470MA 460 MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 470 mA | 600mA | Unshielded | 460mOhm Max | 39 @ 2.52MHz | - | - | -55°C ~ 85°C | 2.52 MHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-121KFIXED IND 120UH 350MA 870MOHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 120 µH | ±10% | 350 mA | 400mA | Unshielded | 870mOhm Max | 48 @ 1kHz | - | - | -55°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
|
|
AIUR-07-151KFIXED IND 150UH 320MA 1.03OHM TH Abracon LLC |
0 |
|
规格书 |
AIUR-07 | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±10% | 320 mA | 400mA | Unshielded | 1.03Ohm Max | 49 @ 1kHz | - | - | -55°C ~ 85°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.201" (5.10mm) |
