固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LQH32NZ6R8K23LFIXED IND 6.8UH 240MA 1.5OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±10% | 240 mA | - | Unshielded | 1.5Ohm Max | 20 @ 1MHz | 25MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ120J23LFIXED IND 12UH 180MA 2 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 12 µH | ±5% | 180 mA | - | Unshielded | 2Ohm Max | 35 @ 1MHz | 18MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ5R6K23LFIXED IND 5.6UH 250MA 1.3OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 5.6 µH | ±10% | 250 mA | - | Unshielded | 1.3Ohm Max | 20 @ 1MHz | 28MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ150J23LFIXED IND 15UH 170MA 2.2 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 15 µH | ±5% | 170 mA | - | Unshielded | 2.2Ohm Max | 35 @ 1MHz | 16MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ8R2K23LFIXED IND 8.2UH 225MA 1.6OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 8.2 µH | ±10% | 225 mA | - | Unshielded | 1.6Ohm Max | 20 @ 1MHz | 23MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ2R2K23LFIXED IND 2.2UH 370MA 800MOHM SM Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.2 µH | ±10% | 370 mA | - | Unshielded | 800mOhm Max | 20 @ 1MHz | 50MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ270J23LFIXED IND 27UH 125MA 3.1 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 27 µH | ±5% | 125 mA | - | Unshielded | 3.1Ohm Max | 35 @ 1MHz | 13MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ121J23LFIXED IND 120UH 75MA 8 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 120 µH | ±5% | 75 mA | - | Unshielded | 8Ohm Max | 40 @ 796kHz | 7.5MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ151J23LFIXED IND 150UH 70MA 9.3 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±5% | 70 mA | - | Unshielded | 9.3Ohm Max | 40 @ 796kHz | 7MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
|
|
LQH32NZ820J23LFIXED IND 82UH 70MA 6.2 OHM SMD Murata Electronics |
0 |
|
规格书 |
LQH32 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 82 µH | ±5% | 70 mA | - | Unshielded | 6.2Ohm Max | 40 @ 1MHz | 8.5MHz | AEC-Q200 | -40°C ~ 105°C | 1 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.087" (2.20mm) |
