固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LRC0603CKR18GV001TFIXED IND 180NH 300MA 2.7OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 180 nH | ±10% | 300 mA | - | Unshielded | 2.7Ohm Max | 8 @ 50MHz | 550MHz | - | -55°C ~ 100°C | 50 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) |
|
|
LRC0603CKR22GV001TFIXED IND 220NH 300MA 2.8OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 220 nH | ±10% | 300 mA | - | Unshielded | 2.8Ohm Max | 8 @ 50MHz | 450MHz | - | -55°C ~ 100°C | 50 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) |
|
|
LRC0201BK33NGV001TFIXED IND 33NH 200MA 2.3 OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 33 nH | ±10% | 200 mA | - | Unshielded | 2.3Ohm Max | 5 @ 100MHz | 1.5GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0201 (0603 Metric) | 0.024" L x 0.012" W (0.60mm x 0.30mm) | 0.013" (0.33mm) |
|
|
LRC0201BK39NGV001TFIXED IND 39NH 200MA 2.5 OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 39 nH | ±10% | 200 mA | - | Unshielded | 2.5Ohm Max | 5 @ 100MHz | 1.4GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0201 (0603 Metric) | 0.024" L x 0.012" W (0.60mm x 0.30mm) | 0.013" (0.33mm) |
.jpg)
|
L-15W2N4SV4EFIXED IND 2.4NH 800MA SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 2.4 nH | ±0.3nH | 800 mA | - | Unshielded | - | - | 6GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.055" (1.40mm) |
|
|
L-15W5N1SV4EFIXED IND 5.1NH 600MA SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 5.1 nH | ±0.3nH | 600 mA | - | Unshielded | - | 60 @ 1GHz | - | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.055" (1.40mm) |
.jpg)
|
L-14W2N2SV4EFIXED IND 2.2NH 700MA 80MOHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 2.2 nH | ±0.3nH | 700 mA | - | Unshielded | 80mOhm Max | - | - | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.041" W (1.60mm x 1.05mm) | 0.049" (1.25mm) |
|
|
L-14W5N1SV4EFIXED IND 5.1NH 700MA 110MOHM SM Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 5.1 nH | ±0.3nH | 700 mA | - | Unshielded | 110mOhm Max | 18 @ 250MHz | 5.4GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.041" W (1.60mm x 1.05mm) | 0.049" (1.25mm) |
|
|
L-14W5N6SV4EFIXED IND 5.6NH 700MA 110MOHM SM Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 5.6 nH | ±0.3nH | 700 mA | - | Unshielded | 110mOhm Max | 16 @ 250MHz | 5GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.041" W (1.60mm x 1.05mm) | 0.049" (1.25mm) |
|
|
L-14W6N2SV4EFIXED IND 6.2NH 700MA 110MOHM SM Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ceramic | 6.2 nH | ±0.3nH | 700 mA | - | Unshielded | 110mOhm Max | - | - | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.041" W (1.60mm x 1.05mm) | 0.049" (1.25mm) |
