场效应晶体管（FETs）、MOSFETs
| 制造商 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部重置
应用所有
结果:
| 图片 | 型号 | 库存 | 价格 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FQAF28N15MOSFET N-CH 150V 22A TO3PF Fairchild Semiconductor |
473 | - |
|
规格书 |
QFET® | TO-3P-3 Full Pack | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 150 V | 22A (Tc) | 10V | 90mOhm @ 11A, 10V | 4V @ 250µA | 52 nC @ 10 V | ±25V | 1600 pF @ 25 V | - | 102W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-3PF |
|
FQPF4N80MOSFET N-CH 800V 2.2A TO220F Fairchild Semiconductor |
334 | - |
|
规格书 |
QFET® | TO-220-3 Full Pack | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 800 V | 2.2A (Tc) | 10V | 3.6Ohm @ 1.1A, 10V | 5V @ 250µA | 25 nC @ 10 V | ±30V | 880 pF @ 25 V | - | 43W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220F-3 |
|
|
FQAF16N25MOSFET N-CH 250V 12.4A TO3PF Fairchild Semiconductor |
682 | - |
|
规格书 |
QFET® | TO-3P-3 Full Pack | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 250 V | 12.4A (Tc) | 10V | 230mOhm @ 6.2A, 10V | 5V @ 250µA | 35 nC @ 10 V | ±30V | 1200 pF @ 25 V | - | 85W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
|
FQAF16N25CMOSFET N-CH 250V 11.4A TO3PF Fairchild Semiconductor |
360 | - |
|
规格书 |
QFET® | TO-3P-3 Full Pack | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 250 V | 11.4A (Tc) | 10V | 270mOhm @ 5.7A, 10V | 4V @ 250µA | 53.5 nC @ 10 V | ±30V | 1080 pF @ 25 V | - | 73W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-3PF |
|
HUFA75545P3MOSFET N-CH 80V 75A TO220-3 Fairchild Semiconductor |
345 | - |
|
规格书 |
UltraFET™ | TO-220-3 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 80 V | 75A (Tc) | 10V | 10mOhm @ 75A, 10V | 4V @ 250µA | 235 nC @ 20 V | ±20V | 3750 pF @ 25 V | - | 270W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220-3 |
|
FQB55N06TMMOSFET N-CH 60V 55A D2PAK Fairchild Semiconductor |
696 | - |
|
规格书 |
QFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 55A (Tc) | 10V | 20mOhm @ 27.5A, 10V | 4V @ 250µA | 46 nC @ 10 V | ±25V | 1690 pF @ 25 V | - | 3.75W (Ta), 133W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
FCPF380N60-F152600V, N-CHANNEL, MOSFET, TO-220 Fairchild Semiconductor |
476 | - |
|
规格书 |
SuperFET® II | TO-220-3 Full Pack | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 10.2A (Tc) | 10V | 380mOhm @ 5A, 10V | 3.5V @ 250µA | 40 nC @ 10 V | ±20V | 1665 pF @ 25 V | - | 31W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220F-3 |
|
FQI9N50TUMOSFET N-CH 500V 9A I2PAK Fairchild Semiconductor |
756 | - |
|
规格书 |
QFET® | TO-262-3 Long Leads, I2PAK, TO-262AA | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 9A (Tc) | 10V | 730mOhm @ 4.5A, 10V | 5V @ 250µA | 36 nC @ 10 V | ±30V | 1450 pF @ 25 V | - | 3.13W (Ta), 147W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-262 (I2PAK) |
|
|
FQB9N50TMMOSFET N-CH 500V 9A D2PAK Fairchild Semiconductor |
485 | - |
|
规格书 |
QFET® | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 9A (Tc) | 10V | 730mOhm @ 4.5A, 10V | 5V @ 250µA | 36 nC @ 10 V | ±30V | 1450 pF @ 25 V | - | 3.13W (Ta), 147W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
|
HUFA75842S3SMOSFET N-CH 150V 43A D2PAK Fairchild Semiconductor |
443 | - |
|
规格书 |
UltraFET™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 150 V | 43A (Tc) | 10V | 42mOhm @ 43A, 10V | 4V @ 250µA | 175 nC @ 20 V | ±20V | 2730 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
