铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PLV1C471MDL1TDCAP ALUM POLY 470UF 20% 16V TH Nichicon |
0 |
|
规格书 |
PLV | Tape & Box (TB) | Obsolete | Polymer | 470 µF | ±20% | 16 V | 23mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.9 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
PLV1D151MCL1TDCAP ALUM POLY 150UF 20% 20V TH Nichicon |
0 |
|
规格书 |
PLV | Cut Tape (CT) | Obsolete | Polymer | 150 µF | ±20% | 20 V | 27mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
PLV1V560MCL1TDCAP ALUM POLY 56UF 20% 35V TH Nichicon |
0 |
|
规格书 |
PLV | Cut Tape (CT) | Obsolete | Polymer | 56 µF | ±20% | 35 V | 29mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.9 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
|
PLV1H330MCL1TDCAP ALUM POLY 33UF 20% 50V TH Nichicon |
0 |
|
规格书 |
PLV | Cut Tape (CT) | Obsolete | Polymer | 33 µF | ±20% | 50 V | 32mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.9 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
|
PLV1J270MDL1TDCAP ALUM POLY 27UF 20% 63V TH Nichicon |
0 |
|
规格书 |
PLV | Tape & Box (TB) | Obsolete | Polymer | 27 µF | ±20% | 63 V | 33mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.1 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | - | Through Hole |
|
PLG0E392MD01CAP ALUM POLY 3900UF 20% 2.5V TH Nichicon |
0 |
|
规格书 |
PLG | Bulk | Obsolete | Polymer | 3900 µF | ±20% | 2.5 V | 8mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
RVB0G151MNGCAP ALUM POLY 150UF 20% 4V SMD Nichicon |
0 |
|
规格书 |
FPCAP, VB | Tape & Reel (TR) | Obsolete | Polymer | 150 µF | ±20% | 4 V | 15mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.118" (3.00mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
|
|
RVA0J101MNGCAP ALUM POLY 100UF 20% 6.3V SMD Nichicon |
0 |
|
规格书 |
FPCAP, VA | Tape & Reel (TR) | Obsolete | Polymer | 100 µF | ±20% | 6.3 V | 25mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.118" (3.00mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
|
|
RVA1C270MNGCAP ALUM POLY 27UF 20% 16V SMD Nichicon |
0 |
|
规格书 |
FPCAP, VA | Tape & Reel (TR) | Obsolete | Polymer | 27 µF | ±20% | 16 V | 55mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.118" (3.00mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
|
|
RVA1C330MNGCAP ALUM POLY 33UF 20% 16V SMD Nichicon |
0 |
|
规格书 |
FPCAP, VA | Tape & Reel (TR) | Obsolete | Polymer | 33 µF | ±20% | 16 V | 55mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | - | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.118" (3.00mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
