铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
GYC1H101MCW1GSCAP ALUMHYB 100UF 20% 50V SMD Nichicon |
81 |
|
规格书 |
GYC | Tape & Reel (TR) | Active | Hybrid | 100 µF | ±20% | 50 V | 28mOhm | 4000 Hrs @ 135°C | -55°C ~ 135°C | AEC-Q200 | Automotive | - | 390 mA @ 120 Hz | 2.6 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.433" (11.00mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
RPS0J102MCN1GSCAP ALUM POLY 1000UF 20% 6.3V Nichicon |
59 |
|
规格书 |
FPCAP, RPS | Tape & Reel (TR) | Active | Polymer | 1000 µF | ±20% | 6.3 V | 12mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 550 mA @ 120 Hz | 5.5 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.488" (12.40mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
PCJ0J182MCL1GSCAP ALUM POLY 1800UF 20% 6.3V Nichicon |
845 |
|
规格书 |
PCJ | Tape & Reel (TR) | Active | Polymer | 1800 µF | ±20% | 6.3 V | 11mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | General Purpose | - | - | 5.2 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
PLV1E151MDL1CAP ALUM POLY 150UF 20% 25V TH Nichicon |
91 |
|
规格书 |
PLV | Bulk | Not For New Designs | Polymer | 150 µF | ±20% | 25 V | 26mOhm | 3000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.4 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | - | Through Hole |
|
RNU1E221MDNASQPXCAP ALUM POLY 220UF 20% 25V TH Nichicon |
1,069 |
|
规格书 |
FPCAP, RNU | Tape & Reel (TR) | Active | Polymer | 220 µF | ±20% | 25 V | 16mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 465 mA @ 120 Hz | 4.65 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
PCK0G182MCO1GSCAP ALUM POLY 1800UF 20% 4V SMD Nichicon |
1,000 |
|
规格书 |
PCK | Tape & Reel (TR) | Active | Polymer | 1800 µF | ±20% | 4 V | 8mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | General Purpose | - | - | 6 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.394" (10.00mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
 R7-Series.jpg)
|
RR70J221MDN1CAP ALUM POLY 220UF 20% 6.3V TH Nichicon |
331 |
|
规格书 |
FPCAP, RR7 | Bulk | Active | Polymer | 220 µF | ±20% | 6.3 V | 7mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 560 mA @ 120 Hz | 5.6 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
RHT1A331MDN1CAP ALUM POLY 330UF 20% 10V TH Nichicon |
188 |
|
规格书 |
FPCAP, RHT | Bulk | Active | Polymer | 330 µF | ±20% | 10 V | 17mOhm | 1000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 395 mA @ 120 Hz | 3.95 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.453" (11.50mm) | - | Through Hole |
|
RSB0E391MCN1GSCAP ALUM POLY 390UF 20% 2.5V SMD Nichicon |
806 |
|
规格书 |
FPCAP, RSB | Tape & Reel (TR) | Active | Polymer | 390 µF | ±20% | 2.5 V | 10mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 365 mA @ 120 Hz | 3.65 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.236" (6.00mm) | 0.256" L x 0.256" W (6.50mm x 6.50mm) | Surface Mount |
|
RR71A221MDN1PHCAP ALUM POLY 220UF 20% 10V TH Nichicon |
1,383 |
|
规格书 |
FPCAP, RR7 | Cut Tape (CT) | Active | Polymer | 220 µF | ±20% | 10 V | 7mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 610 mA @ 120 Hz | 6.1 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole |
