通孔式电阻器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 电阻 | 容差 | 功率 (W) | 成分 | 特性 | 温度系数 | 工作温度 | 供应商器件封装 | 尺寸 / 尺寸 | 高度 - 安装（最大值） | 端子数 | 故障率 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PR02000201000JR500RES 100 OHM 5% 2W AXIAL Vishay Beyschlag/Draloric/BC Components |
24,506 |
|
规格书 |
PR02 | Tape & Reel (TR) | Active | 100 Ohms | ±5% | 2W | Metal Film | Automotive AEC-Q200, Flame Retardant Coating, Fusible, Safety | ±250ppm/°C | -55°C ~ 200°C | Axial | 0.154" Dia x 0.394" L (3.90mm x 10.00mm) | - | 2 | - |
|
AC05000001007JAC00RES 0.1 OHM 5W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
4,260 |
|
规格书 |
AC | Cut Tape (CT) | Active | 100 mOhms | ±5% | 5W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.295" Dia x 0.709" L (7.50mm x 18.00mm) | - | 2 | - |
|
VR68000003305JAC00RES 33M OHM 1W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
26,111 |
|
规格书 |
VR68 | Cut Tape (CT) | Active | 33 MOhms | ±5% | 1W | Metal Film | High Voltage, Pulse Withstanding | ±200ppm/°C | -55°C ~ 155°C | Axial | 0.268" Dia x 0.709" L (6.80mm x 18.00mm) | - | 2 | - |
|
|
VR68000001004JAC00RES 1M OHM 1W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
7,497 |
|
规格书 |
VR68 | Cut Tape (CT) | Active | 1 MOhms | ±5% | 1W | Metal Film | High Voltage, Pulse Withstanding | ±200ppm/°C | -55°C ~ 155°C | Axial | 0.268" Dia x 0.709" L (6.80mm x 18.00mm) | - | 2 | - |
|
AC03000001009JACCSRES 10 OHM 3W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
14,310 |
|
规格书 |
AC03 | Cut Tape (CT) | Active | 10 Ohms | ±5% | 3W | Wirewound | Flame Retardant Coating, Fusible, Pulse Withstanding, Safety | ±200ppm/°C | -40°C ~ 200°C | Axial | 0.217" Dia x 0.512" L (5.50mm x 13.00mm) | - | 2 | - |
|
|
AC03000001000JAC00RES 100 OHM 3W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
67,122 |
|
规格书 |
AC | Cut Tape (CT) | Active | 100 Ohms | ±5% | 3W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.189" Dia x 0.512" L (4.80mm x 13.00mm) | - | 2 | - |
|
AC01000001008JA100RES 1 OHM 1W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
12,909 |
|
规格书 |
AC | Cut Tape (CT) | Active | 1 Ohms | ±5% | 1W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.169" Dia x 0.433" L (4.30mm x 11.00mm) | - | 2 | - |
|
|
AC07000004708JAC00RES 4.7 OHM 7W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
2,537 |
|
规格书 |
AC | Cut Tape (CT) | Active | 4.7 Ohms | ±5% | 7W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.295" Dia x 1.024" L (7.50mm x 26.00mm) | - | 2 | - |
|
|
AC05000001009JAC00RES 10 OHM 5W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
36,793 |
|
规格书 |
AC | Cut Tape (CT) | Active | 10 Ohms | ±5% | 5W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.295" Dia x 0.709" L (7.50mm x 18.00mm) | - | 2 | - |
|
|
AC05000001008JAC00RES 1 OHM 5W 5% AXIAL Vishay Beyschlag/Draloric/BC Components |
14,958 |
|
规格书 |
AC | Cut Tape (CT) | Active | 1 Ohms | ±5% | 5W | Wirewound | Flame Retardant Coating, Pulse Withstanding, Safety | -10/ -80ppm/°C | -40°C ~ 275°C | Axial | 0.295" Dia x 0.709" L (7.50mm x 18.00mm) | - | 2 | - |
