测试探针尖端
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 尖头 - 类型 | 连接类型 | 尖端长度 | 长度 - 总体 | 颜色 | 电压额定值 | 额定值 | 数量 | 电流额定值（安培） | 材质 - 本体 | 尖端材料 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TOP100A15/150GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Pyramid Head, 0.059" (1.50mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
R100SICT Receptacle |
0 |
|
规格书 |
- | Bag | Active | Spring Tip - Solder Connection | - | 0.186" (4.72mm) | 1.170" (29.72mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | - | -55°C ~ 120°C |
|
TOP050W05/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP050 | Box | Active | Spring Tip - Dagger Head, 0.020" (0.50mm) Dia | - | 0.272" (6.90mm) | 1.700" (43.15mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100E15/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Cup Head, 0.059" (1.50mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100A15/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Pyramid Head, 0.059" (1.50mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100ZH15/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Crown Head | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP050I064/100GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP050 | Box | Active | Spring Tip - Serrated Head, 0.025" (0.64mm) Dia | - | 0.272" (6.90mm) | 1.700" (43.15mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100W09/250GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Dagger Head, 0.035" (0.90mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100H15/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Crown Head, 0.059" (1.50mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
R050SICT TEST PROBE RECEPTACLE |
0 |
|
规格书 |
- | Bag | Active | Spring Tip - Solder Connection | - | 0.220" (5.59mm) | 1.600" (40.64mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | - | -55°C ~ 120°C |
|
R075WICT TEST PROBE RECEPTACLE |
0 |
|
规格书 |
- | Bag | Active | Spring Tip - Wire-Wrap | - | 0.585" (14.86mm) | 1.550" (39.37mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | - | -55°C ~ 120°C |
|
|
TOP100I064/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Serrated Head, 0.025" (0.64mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
R156SICT TEST PROBE RECEPTACLE |
0 |
|
规格书 |
- | Bag | Active | Spring Tip - Solder Connection | - | 0.220" (5.59mm) | 1.200" (30.48mm) | - | - | - | - | 5 A | Phosphor Copper, Gold Plated | - | -55°C ~ 120°C |
|
|
TOP075RF065/200GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP075 | Box | Active | Spring Tip - Needle Head | - | 0.388" (9.85mm) | 1.300" (33.00mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100I31/200GINTERFACE PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Serrated Head, 0.122" (3.10mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100E15/150GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Cup Head, 0.059" (1.50mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
R187SICT TEST PROBE RECEPTACLE |
0 |
|
规格书 |
- | Bag | Active | Spring Tip - Solder Connection | - | 0.220" (5.59mm) | 1.320" (33.53mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | - | -55°C ~ 120°C |
|
|
TOP100I064/100GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Serrated Head, 0.025" (0.64mm) Dia | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP075H05/280GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP075 | Box | Active | Spring Tip - Crown Head, 0.020" (0.50mm) Dia | - | 0.388" (9.85mm) | 1.300" (33.00mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
|
|
TOP100H13/280GICT SPRING CONTACT TEST PROBE |
0 |
|
规格书 |
TOP100 | Box | Active | Spring Tip - Crown Head | - | 0.329" (8.35mm) | 1.310" (33.27mm) | - | - | - | - | 3 A | Phosphor Copper, Gold Plated | Steel, Beryllium Copper, Gold Plated | -55°C ~ 120°C |
