选择器开关
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电路 | 位置数量 | 开关功能 | 电流额定值（安培） | 电压额定值 - 交流 | 电压额定值 - 直流 | 照明 | 照明类型，颜色 | 照明电压（额定值） | 安装类型 | 端接样式 | 面板开孔尺寸 | 防护等级 | 特性 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
W22S3-HW-10/10SWITCH SELECT 3POS DPST 10A 72V |
155 |
|
- |
22 | Bag | Active | Standard | DPST-NO | 3 | On-Off-Off, Off-Off-On | 10A (AC), 2.5A (DC) | 72 V | 28 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.50mm Dia | IP66 - Dust Tight, Water Resistant | - | -40°C ~ 55°C |
|
|
W22S2-HW-20SWITCH SELECT 2POS DPST 10A 72V |
138 |
|
规格书 |
22 | Bag | Active | Standard | DPST-NO | 2 | Off-On | 10A (AC), 2.5A (DC) | 72 V | 28 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.50mm Dia | IP66 - Dust Tight, Water Resistant | - | -40°C ~ 55°C |
|
NS22-SL21A00SWITCH SELECT 2POS SPST 3A 250V |
920 |
|
规格书 |
NS22 | Bulk | Active | Standard | SPST-NO | 2 | Off-On | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
|
NS22-S21A01BSWITCH SELECT 2POS DPST 3A 250V |
990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | Off-On | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
|
NS22-SL21A01BSWITCH SELECT 2POS DPST 3A 250V |
990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | Off-On | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
|
NS22-S21A01ASWITCH SELECT 2POS DPST 3A 250V |
980 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO | 2 | Off-On | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
|
NS22-S31A01BSWITCH SELECT 3POS DPST 3A 250V |
980 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 3 | Off-On-Off | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
|
NS22-S31A01ASWITCH SELECT 3POS DPST 3A 250V |
970 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO | 3 | On-Off-On | 3A (AC), 270mA (DC) | 250 V | 250 V | Non-Illuminated | - | - | Panel Mount | Screw Terminal | Circular - 22.30mm Dia | IP65 - Dust Tight, Water Resistant | - | -25°C ~ 70°C |
|
M6S-A20S1-12EBSWITCH SELECT 2POS SPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | SPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Illuminated | LED, Blue | 12 VDC | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
M6S-A20S1-06EGSWITCH SELECT 2POS SPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | SPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Illuminated | LED, Green | 6 VDC | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
|
M6S-A20S2-110GSWITCH SELECT 2POS DPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | DPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Illuminated | Neon, Green | 110 VAC | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
M6S-A20S2-24EWSWITCH SELECT 2POS DPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | DPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Illuminated | LED, White | 24 VDC | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
|
M6S-A30S2-WSWITCH SELECT 3POS SPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | SPDT | 3 | On-On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Non-Illuminated | - | - | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
|
M6S-A20S2-110BSWITCH SELECT 2POS DPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | DPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Illuminated | Neon, Blue | 110 VAC | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
|
|
NS22-S3R-L3CG1A1B22mm SELECTOR SWITCH |
1,990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 3 | On-Off-Mom | 3A (AC/DC) | 250 V | 24 V | Illuminated | LED, Green | 24 VDC | Panel Mount | Screw Terminal | Circular - 22.00mm Dia | IP66 - Dust Tight, Water Resistant | Bezel - Round, Black Knob | -40°C ~ 70°C |
|
|
NS22-S2-L3CG1A1B22mm SELECTOR SWITCH |
1,990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | On-Off, Off-On | 3A (AC/DC) | 250 V | 24 V | Illuminated | LED, Green | 24 VDC | Panel Mount | Screw Terminal | Circular - 22.00mm Dia | IP66 - Dust Tight, Water Resistant | Bezel - Round, Black Knob | -40°C ~ 70°C |
|
|
NS22-SL2-L2CR1A1B22mm SELECTOR SWITCH |
1,990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | On-Off, Off-On | 3A (AC/DC) | 250 V | 24 V | Illuminated | LED, Red | 12 VDC | Panel Mount | Screw Terminal | Circular - 22.00mm Dia | IP66 - Dust Tight, Water Resistant | Bezel - Round, Black Knob | -40°C ~ 70°C |
|
|
NS22-SL2-L1CR1A1B22mm SELECTOR SWITCH |
1,980 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | On-Off, Off-On | 3A (AC/DC) | 250 V | 24 V | Illuminated | LED, Red | 6 VDC | Panel Mount | Screw Terminal | Circular - 22.00mm Dia | IP66 - Dust Tight, Water Resistant | Bezel - Round, Black Knob | -40°C ~ 70°C |
|
|
NS22-SA2-L1CB1A1B22mm SELECTOR SWITCH |
1,990 |
|
规格书 |
NS22 | Bulk | Active | Standard | DPST-NO/NC | 2 | On-Mom, Off-Mom | 3A (AC/DC) | 250 V | 24 V | Illuminated | LED, Blue | 6 VDC | Panel Mount | Screw Terminal | Circular - 22.00mm Dia | IP66 - Dust Tight, Water Resistant | Bezel - Round, Black Knob | -40°C ~ 70°C |
|
M6S-B20S1-GSWITCH SELECT 2POS SPDT 2A 250V |
2,500 |
|
规格书 |
M6 | Retail Package | Active | Standard | SPDT | 2 | On-On | 2A (AC), 400mA (DC) | 250 V | 125 V | Non-Illuminated | - | - | Panel Mount | Quick Connect - 0.110" (2.8mm) | Circular - 16.20mm Dia | IP65 - Dust Tight, Water Resistant | UL94 V-0 | -25°C ~ 55°C |
