首页 > 产品中心 > 隔离器 > 光耦合器、光隔离器 > 三端双向可控硅、SCR 输出光隔离器

三端双向可控硅、SCR 输出光隔离器

制造商	系列	封装/外壳	包装	产品状态	输出类型	零交叉电路	通道数	电压 - 隔离	电压 - 关断状态	静态 dV/dt（最小值）	电流 - LED 触发 (Ift)（最大值）	电流 - 导通状态 (It (RMS))（最大值）	电流 - 保持 (Ih)	开启时间	电压 - 正向 (Vf)（典型值）	电流 - 直流正向（If）（最大值）	工作温度	安装类型	供应商设备封装	认证机构
American Bright Optoelectronics Corporation Central Semiconductor Corp Fairchild Semiconductor Fairchild/ON Semiconductor Lite-On Inc. onsemi Panasonic Electric Works Sharp Microelectronics SHARP/Socle Technology Texas Instruments Toshiba Semiconductor and Storage Vicor Corporation Vishay Semiconductor Opto Division Weidmuller Würth Elektronik	* - 3SD11 APC-305X APT ELM302X ELM306X ELM308X ELRX223 H11J H11J1 H11J2 H11J3 H11J4 H11J5 IS3020 IS3021 IS3022 IS3051 IS3052 IS6005 IS6010 IS6015 IS607 IS608 IS62 MF301x MF302x MF303x MF304x MF306x MOC3009 MOC301 MOC302 MOC302x MOC3030 MOC3031 MOC3032 MOC3033 MOC303x MOC304 MOC305 MOC3051 MOC305x MOC306 MOC306x MOC308 MOC308x Q302X Q305X Q306X Q308X QTM302X QTM303X QTM304X QTM305X QTM306X QTM308X QTTX213 QTX213 QTX223 S2S4 TLP VO3021 VO3022 VO3023 WAVESERIES WL-OCTR	- 16-DIP (0.300", 7.62mm), 10 Leads 4-DIP (0.300", 7.62mm) 4-DIP (0.400", 10.16mm) 4-SIP 4-SMD 4-SMD (0.300", 7.62mm) 4-SMD, Gull Wing 4-SOIC (0.173", 4.40mm Width) 5-SMD, Gull Wing 6-DIP (0.300", 7.62mm) 6-DIP (0.300", 7.62mm), 5 Leads 6-DIP (0.400", 10.16mm) 6-DIP (0.400", 10.16mm), 5 Leads 6-SMD 6-SMD (5 Leads), Gull Wing 6-SMD, Gull Wing 6-SMD, Gull Wing, 5 Leads 6-SOIC (0.173", 4.40mm Width), 4 Leads 8-DIP (0.300", 7.62mm) 8-DIP (0.300", 7.62mm), 7 Leads 8-SMD (7 Leads), Gull Wing Din Rail Module	Box Bulk Cut Tape (CT) Tape & Reel (TR) Tube	Active Discontinued at Digi-Key Last Time Buy Obsolete	- SCR Triac Triac, Power	- No Yes	- 1 2	- 2500Vrms 3000Vrms 3750Vrms 4000Vrms 4170Vrms 4470Vrms 5000Vrms 5300Vrms 7500Vpk	- 200 V 250 V 300 V 400 V 450 V 600 V 700 V 800 V	- 1.5kV/µs 100V/µs 100V/µs (Typ) 10kV/µs 10kV/µs (Typ) 10V/µs (Typ) 12V/µs 1kV/µs 200V/µs 210V/µs (Typ) 2kV/µs (Typ) 30V/µs 3V/µs 500V/µs 500V/µs (Typ) 50V/µs 50V/µs (Typ) 5kV/µs 5V/µs 600V/µs 600V/µs (Typ) 800V/µs	- 1.2mA 1.3mA 1.6mA 10mA 14mA 15mA 20mA 25mA 2mA 30mA 3mA 5mA 6mA 700µA (Typ) 7mA 8mA	- 1 A 1.2 A 100 mA 15 mA 150 mA 200 mA 300 mA 50 mA 600 mA 70 mA 8 A 80 mA 900 mA	- 100µA 100µA (Typ) 1mA 1mA (Typ) 200µA 200µA (Typ) 220µA (Typ) 237µA (Typ) 250µA 250µA (Typ) 257µA 257µA (Typ) 25mA 280µA 280µA (Typ) 3.5mA 300µA (Typ) 3mA 400µA 400µA (Typ) 450µA (Typ) 500µA 500µA (Typ) 50mA 540µA (Typ) 5mA 600µA 600µA (Typ)	- 100µs 100µs (Max) 10ms (Max) 10µs 10µs (Max) 15µs 1ms (Max) 20µs 30µs 35µs 50µs (Max) 60µs 8µs	- 1.15V 1.16V 1.18V 1.1V 1.21V 1.24V 1.25V 1.27V 1.28V 1.2V 1.3V 1.3V (Max) 1.4V 1.4V (Max) 1.5V (Max)	- 1 A 15 mA 20 mA 25 mA 3 mA 30 mA 50 mA 6 mA 60 mA 80 mA	- -25°C ~ 100°C -25°C ~ 50°C -25°C ~ 85°C -30°C ~ 100°C -30°C ~ 85°C -40°C ~ 100°C -40°C ~ 110°C -40°C ~ 85°C -55°C ~ 100°C -55°C ~ 110°C -55°C ~ 85°C	- DIN Rail Surface Mount Through Hole	- 10-DIP 4-DIP 4-DIP Gull Wing 4-DIP-M 4-DIP-SL 4-MFP 4-Mini-Flat 4-SIP 4-SMD 4-SOP 4-SOP (2.54mm) 5-SMD 6-DIP 6-DIP (Cut), 5 Lead 6-DIP Gull Wing 6-MFSOP, 4 Lead 6-PDIP 6-SMD 6-SO, 5 Lead 6-SOP 7-DIP 7-SMD 8-DIP 8-SMD Module SMD	- BSI, CQC, CSA, cUR, UR, VDE BSI, CQC, cUR, FIMKO, UR, VDE BSI, CQC, UR, VDE BSI, CSA, cUR, FIMKO, UR BSI, CSA, cUR, FIMKO, UR, VDE BSI, CSA, cUR, UR BSI, CSA, DEMKO, FIMKO, SEMKO, UR, VDE BSI, CSA, UL BSI, CSA, UL, VDE BSI, cUR, FIMKO, UR BSI, cUR, FIMKO, UR, VDE BSI, DEMKO, SEMKO, UR, VDE BSI, SEMKO, UR BSI, SEMKO, UR, VDE BSI, UR, VDE CQC, CSA, cUL, FIMKO, UL CQC, CSA, cUL, FIMKO, UL, VDE CQC, CSA, cUL, UL CQC, CSA, cUL, UL, VDE CQC, CSA, cUR, UR CQC, CSA, cUR, UR, VDE CQC, CSA, TUV, UL, VDE CQC, cUL, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE CQC, cUL, UL, VDE CQC, cULus, cURus, UL, VDE CQC, cUR, UR CQC, cUR, UR, VDE CQC, UL CQC, UL, VDE CSA, cUL, UL CSA, cUL, UL, VDE CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE CSA, DEMKO, FIMKO, NEMKO, SEMKO, UR, VDE CSA, DIN, UR CSA, FIMKO, UL CSA, UL CSA, UL, VDE CSA, UR CSA, UR, VDE cUL, Demko, Fimko, Nemko, Semko, UL cUL, Demko, Fimko, Nemko, Semko, UL, VDE cUL, FIMKO, UL cUL, FIMKO, UL, VDE cUL, UL cUL, UL, VDE cUL, UR, VDE cUR, FIMKO, UR cUR, FIMKO, UR, VDE cUR, UR cUR, UR, VDE cUR, VDE DEMKO, FIMKO, NEMKO, SEMKO, UL DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE IEC/EN/DIN, UL SEMKO, UR UL UL, VDE UR UR, VDE VDE

全部重置

应用所有

结果:

图片	型号	库存	价格	数量	规格书	系列	封装/外壳	包装	产品状态	输出类型	零交叉电路	通道数	电压 - 隔离	电压 - 关断状态	静态 dV/dt（最小值）	电流 - LED 触发 (Ift)（最大值）	电流 - 导通状态 (It (RMS))（最大值）	电流 - 保持 (Ih)	开启时间	电压 - 正向 (Vf)（典型值）	电流 - 直流正向（If）（最大值）	工作温度	安装类型	供应商设备封装	认证机构
	MOC3012 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	3,871	-	立即询盘	规格书	-	6-DIP (0.300", 7.62mm)	Bulk	Active	Triac	No	1	7500Vpk	250 V	12V/µs	5mA	100 mA	100µA	-	1.2V	50 mA	-40°C ~ 100°C	Through Hole	6-PDIP	UL
	MOC3021 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	4,804	-	立即询盘	规格书	-	6-DIP (0.300", 7.62mm)	Tube	Obsolete	Triac	No	1	5300Vrms	400 V	-	15mA	-	100µA	-	-	50 mA	-	Through Hole	6-DIP	-
	TIL3022 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	43,850	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	TIL3012 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	22,068	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	TIL3010 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	7,200	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	TIL3023 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	3,730	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	TIL3021 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	2,200	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	MOC3010 OPTOISO 5300VRMS TRIAC 1CH 6DIP Texas Instruments	5,434	-	立即询盘	规格书	-	6-DIP (0.300", 7.62mm)	Tube	Obsolete	Triac	No	1	5300Vrms	250 V	-	15mA	-	100µA (Typ)	-	1.15V	60 mA	-40°C ~ 85°C	Through Hole	6-DIP	UL, VDE
	TIL3009 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	2,850	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
	TIL3020 TRIAC OUTPUT OPTOCOUPLER Texas Instruments	2,930	-	立即询盘	规格书	*	-	Bulk	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
