多导体电缆
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 电缆类型 | 导体数量 | 线规 | 导体股数 | 导体材料 | 护套（绝缘）材料 | 护套（绝缘）直径 | 屏蔽类型 | 长度 | 护套颜色 | 额定值 | 特性 | 电压 | 工作温度 | 用途 | 护套（绝缘）厚度 | 导体绝缘 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1023275/500LFLEX SERVO FD 7DSL 4G1,5+(2X22A |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Conductor | 5 | 16 AWG, 22 AWG | - | Copper, Bare | Polyurethane (PU) | 0.256" (6.50mm) | - | - | Orange | - | - | 600 V | -25°C ~ 90°C | - | - | Polyethylene (XLPE), Irradiated | - |
|
|
0028136/500LFLEX ROBOT 900 DP 5X2X0,34 |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Pair | 10 (5 Pair Twisted) | 22 AWG | - | Copper, Bare | Polyurethane (PU) | 0.358" (9.09mm) | Spiral | - | Black | - | - | 500 V | -50°C ~ 80°C | - | - | Thermoplastic Elastomer (TPE) | - |
|
E2012S.30.10CABLE 12COND 22AWG GRAY SHLD 50' |
0 |
|
规格书 |
- | Bulk | Discontinued at Digi-Key | Multi-Conductor | 12 | 22 AWG | 7/30 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.225" (5.72mm) | Foil | 50.00' (15.24m) | Gray | - | Drain Wire | 300 V | -20°C ~ 75°C | Alarm, Security, Sound | 0.0080" (0.203mm) | Poly-Vinyl Chloride (PVC) | - |
|
6502FE 877500CABLE 4COND 22AWG NAT SHLD 100' |
0 |
|
规格书 |
- | Bulk | Active | Multi-Conductor | 4 | 22 AWG | 7/30 | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC) | 0.147" (3.73mm) | Foil | 100.0' (30.5m) | Natural | UL Style CMP | Drain Wire, Rip Cord | - | 0°C ~ 75°C | Alarm, Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
0046711/500LFLEX HEAT 180 C MS 5G1,0 |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Conductor | 2 | 18 AWG | - | Copper, Tinned | Silicone Rubber | 0.256" (6.50mm) | - | - | Black | - | - | 1000 V | -50°C ~ 150°C | - | - | Silicone Rubber | - |
|
2170296CABLE CAT5E 8COND 24AWG TEAL 50' |
0 |
|
规格书 |
ETHERLINE® | Bulk | Active | Multi-Pair, Cat5e | 8 (4 Pair Twisted) | 24 AWG | Solid | Copper, Bare | Low Smoke Zero Halogen (LSZH) | 0.248" (6.30mm) | Foil, Braid | 50.00' (15.24m) | Teal | - | Flame Retardant | 125 V | -30°C ~ 80°C | Industrial, Network | - | - | - |
|
30-00374CABLE 3COND 24AWG BLACK 30M |
0 |
|
规格书 |
- | Spool | Discontinued at Digi-Key | Multi-Conductor | 3 | 24 AWG | 11/34 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.165" (4.19mm) | - | 98.43' (30.00m) | Black | UL Style 2464 | - | 300 V | 80°C | - | 0.0299" (0.759mm) | Poly-Vinyl Chloride (PVC) | - |
|
30-00375CABLE 3COND 24AWG WHITE 30M |
0 |
|
规格书 |
- | Spool | Discontinued at Digi-Key | Multi-Conductor | 3 | 24 AWG | 11/34 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.165" (4.19mm) | - | 98.43' (30.00m) | White | UL Style 2464 | - | 300 V | 80°C | - | 0.0299" (0.759mm) | Poly-Vinyl Chloride (PVC) | - |
|
221203CABLE 3COND 12AWG BLACK 25' |
0 |
|
规格书 |
ÖLFLEX® | Bulk | Discontinued at Digi-Key | Multi-Conductor | 3 | 12 AWG | 56/0.0122" | Copper, Bare | Thermoplastic Polymer | 0.423" (10.74mm) | - | 25.00' (7.62m) | Black | - | Oil Resistant | - | - | Industrial | - | Poly-Vinyl Chloride (PVC), Polyamide (PA), Nylon | - |
|
|
1023294/500LFLEX SERVO 7DSL 4G2,5+(2X1)+(2X |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Conductor | 4 | 14 AWG, 18 AWG, 22 AWG | - | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.256" (6.50mm) | - | - | Orange | - | - | 1000 V | -40°C ~ 80°C | - | - | Polypropylene (PP) | - |
|
|
221618/610LFLEX TRAY II 18G1.5 16/18C |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Conductor | 18 | 16 AWG | - | Copper, Bare | Thermoplastic Polymer | 0.654" (16.60mm) | - | - | Black | - | - | 600 V | -25°C ~ 90°C | - | - | Poly-Vinyl Chloride (PVC), Nylon | - |
|
30-01195CABLE 10COND 24AWG BLK SHLD 5M |
0 |
|
规格书 |
- | Bulk | Discontinued at Digi-Key | Multi-Conductor | 10 | 24 AWG | 41/0.0031" | Copper, Tinned | Thermoplastic Polyurethane (TPU) | 0.236" (5.99mm) | Spiral | 16.40' (5.00m) | Black | ISO 10993 | Biological Compatibility | 150 V | -40°C ~ 70°C | - | 0.0197" (0.500mm) | High Density Polyethylene (HDPE) | - |
|
|
8710040/500LFLEX CHAIN TM 4G10AWG |
0 |
|
- |
ÖLFLEX® | Bulk | Active | Multi-Conductor | 4 | 10 AWG | 192/0.0079" | Copper, Bare | Thermoplastic Polymer | 0.600" (15.24mm) | - | - | Black | - | - | - | - | - | - | Poly-Vinyl Chloride (PVC), Polyamide (PA), Nylon | - |
|
E2033S.30.10CABLE 3COND 18AWG GRAY SHLD 100' |
0 |
|
规格书 |
- | Spool | Discontinued at Digi-Key | Multi-Conductor | 3 | 18 AWG | 7/26 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.168" (4.27mm) | Foil | 100.0' (30.5m) | Gray | - | Drain Wire, Rip Cord | 300 V | -20°C ~ 75°C | Alarm, Security, Sound | 0.0150" (0.381mm) | Poly-Vinyl Chloride (PVC) | - |
|
5500UG 008C500CABLE 2COND 22AWG GRAY 500' |
0 |
|
规格书 |
- | Spool | Obsolete | Multi-Conductor | 2 | 22 AWG | 7/30 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.114" (2.89mm) | - | 500.0' (152.4m) | Gray | - | - | - | -20°C ~ 75°C | Alarm, Security, Sound | 0.0150" (0.381mm) | Polypropylene (PP) | - |
|
|
5500UG 009C500CABLE 2COND 22AWG WHITE 500' |
0 |
|
规格书 |
- | Spool | Obsolete | Multi-Conductor | 2 | 22 AWG | 7/30 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.114" (2.89mm) | - | 500.0' (152.4m) | White | - | - | - | -20°C ~ 75°C | Alarm, Security, Sound | 0.0150" (0.381mm) | Polypropylene (PP) | - |
|
701711CABLE 6 COND 14/18AWG BLACK 10' |
0 |
|
规格书 |
ÖLFLEX® VFD 1XL with Signal | Bulk | Active | Multi-Conductor | 6 (1 Pair + 4) | 14 AWG, 18 AWG | 41/30 | Copper, Tinned | Thermoplastic Elastomer (TPE) | 0.486" (12.34mm) | Foil, Braid | 10.00' (3.05m) | Black | - | Chemical Resistant, Drain Wire, Oil Resistant, UV Resistant | - | - | Industrial | - | Polyethylene (XLPE), Irradiated | - |
|
|
6002MULTI-PAIR 4COND 22AWG/24AWG 25' |
0 |
|
规格书 |
Unitronic® | Bulk | Active | Multi-Pair | 4 (2 Pair) | 22 AWG, 24 AWG | - | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.283" (7.19mm) | Foil, Braid | 25.00' (7.62m) | Gray | - | Oil Resistant | 300 V | -20°C ~ 75°C | Network | - | Poly-Vinyl Chloride (PVC), Polyethylene (PE) | - |
|
85223CY BK005CABLE 3COND 22AWG BLK SHLD 10' |
0 |
|
规格书 |
Xtra-Guard® Flex | Spool | Active | Multi-Conductor | 3 | 22 AWG | 41/38 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.329" (8.36mm) | Braid | 10.00' (3.05m) | Black | UL Style 2587 | Oil Resistant | 600 V | - | - | 0.0350" (0.889mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
470125YY GE432CABLE 12COND 21AWG GRAY 10M |
0 |
|
规格书 |
Pro-Met® | Bulk | Active | Multi-Conductor | 12 | 21 AWG | 20/0.0070" | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.363" (9.22mm) | - | 32.81' (10.00m) | Gray | - | Chemical Resistant, Oil Resistant, UV Resistant | 300 V | -40°C ~ 80°C | Industrial | 0.0374" (0.950mm) | Poly-Vinyl Chloride (PVC) | - |
