高频（RF）继电器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 线圈类型 | 线圈电流 | 线圈电压 | 触点形式 | 触点额定值（电流） | 切换电压 | 必须动作电压 | 必须释放电压 | 动作时间 | 释放时间 | 特性 | 安装类型 | 端接样式 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ARJ20A03ZRELAY RF DPDT 300MA 3V |
0 |
|
规格书 |
ARJ | Tape & Reel (TR) | Active | Non Latching | 66.7 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | 0.3 VDC | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ20A03XRELAY RF DPDT 300MA 3V |
0 |
|
- |
ARJ | Tape & Reel (TR) | Active | Non Latching | 66.7 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | 0.3 VDC | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ22A24ZRELAY RF DPDT 300MA 24V |
0 |
|
规格书 |
ARJ | Tape & Reel (TR) | Active | Latching, Dual Coil | 6.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | - | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ22A24XRELAY RF DPDT 300MA 24V |
0 |
|
- |
ARJ | Tape & Reel (TR) | Active | Latching, Dual Coil | 6.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | - | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
B41-0002RELAY RF SPST-NO X 4 250MA 3.3V |
0 |
|
规格书 |
B41 | Tape & Reel (TR) | Obsolete | Non Latching | 60 mA | 3.3VDC | SPST-NO (1 Form A) x 4 | 250 mA | 125VAC, 125VDC - Max | 2.4 VDC | 0.4 VDC | 0.1 ms | 0.03 ms | - | Surface Mount | BGA | -20°C ~ 85°C |
|
MW4-12ARELAY RF 12A 4GHZ HIGH FREQ |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MW6-12ARELAY RF 12A 6GHZ HIGH FREQ |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
ARJ204HRELAY RF DPDT 300MA 4.5V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 44.4 mA | 4.5VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 3.38 VDC | 0.45 VDC | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ2012RELAY RF DPDT 300MA 12V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 16.7 mA | 12VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 9 VDC | 1.2 VDC | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ2212RELAY RF DPDT 300MA 12V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 12.5 mA | 12VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 9 VDC | - | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ224HRELAY RF DPDT 300MA 4.5V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 33.3 mA | 4.5VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 3.38 VDC | - | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ22A4HRELAY RF DPDT 300MA 4.5V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 33.3 mA | 4.5VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 3.38 VDC | - | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ22A03RELAY RF DPDT 300MA 3V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 50 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | - | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ2003RELAY RF DPDT 300MA 3V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 66.7 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | 0.3 VDC | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ2024RELAY RF DPDT 300MA 24V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 8.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | 2.4 VDC | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ20A03RELAY RF DPDT 300MA 3V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 66.7 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | 0.3 VDC | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ20A24RELAY RF DPDT 300MA 24V |
0 |
|
规格书 |
ARJ | Tube | Active | Non Latching | 8.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | 2.4 VDC | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
|
|
ARJ2203RELAY RF DPDT 300MA 3V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 50 mA | 3VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 2.25 VDC | - | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ2224RELAY RF DPDT 300MA 24V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 6.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | - | 5 ms | 5 ms | - | Through Hole | PC Pin | -30°C ~ 70°C |
|
|
ARJ22A24RELAY RF DPDT 300MA 24V |
0 |
|
规格书 |
ARJ | Tube | Active | Latching, Dual Coil | 6.3 mA | 24VDC | DPDT (2 Form C) | 300 mA | 30VDC - Max | 18 VDC | - | 5 ms | 5 ms | - | Surface Mount | Gull Wing | -30°C ~ 70°C |
