固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XAL6060-223MECFIXED IND 22UH 5A 60.63MOHM SM Coilcraft |
17,126 |
|
规格书 |
XAL60XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 22 µH | ±20% | 5 A | 5.6A | Shielded | 60.63mOhm Max | - | 9MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
|
XEL6060-222MECFIXED IND 2.2UH 18.1A 6.7MOHM SM Coilcraft |
9,774 |
|
规格书 |
XEL6060 | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 2.2 µH | ±20% | 18.1 A | 16A | Shielded | 6.7mOhm Max | - | 33MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
|
XAL6060-562MECFIXED IND 5.6UH 10A 15.9MOHM SM Coilcraft |
8,062 |
|
规格书 |
XAL60XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 5.6 µH | ±20% | 10 A | 9.9A | Shielded | 15.9mOhm Max | - | 20MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
|
XEL6060-472MECFIXED IND 4.7UH 12.1A 15.02MOHM Coilcraft |
7,693 |
|
规格书 |
XEL6060 | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 4.7 µH | ±20% | 12.1 A | 11.4A | Shielded | 15.02mOhm Max | - | 23MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
|
XAL6060-822MECFIXED IND 8.2UH 8A 26.4MOHM SM Coilcraft |
6,935 |
|
规格书 |
XAL60XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 8.2 µH | ±20% | 8 A | 8.4A | Shielded | 26.4mOhm Max | - | 16MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
XGL6060-332MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
4,624 |
|
规格书 |
XGL6060 | Nonstandard | Strip | Active | Molded | Metal Composite | 3.3 µH | ±20% | 16.6 A | 13.4A | Shielded | 6.5mOhm Max | - | 24MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.240" (6.10mm) |
|
|
XGL6060-472MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
3,668 |
|
规格书 |
XGL6060 | Nonstandard | Strip | Active | Molded | Metal Composite | 4.7 µH | ±20% | 14.3 A | 10.2A | Shielded | 10.1mOhm Max | - | 19MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.240" (6.10mm) |
|
|
XGL6060-102MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
3,526 |
|
规格书 |
XGL6060 | Nonstandard | Strip | Active | Molded | Metal Composite | 1 µH | ±20% | 22 A | 23A | Shielded | 2.9mOhm Max | - | 46MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.240" (6.10mm) |
|
|
XAL6060-682MECFIXED IND 6.8UH 9A 20.8MOHM SM Coilcraft |
2,830 |
|
规格书 |
XAL60XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 6.8 µH | ±20% | 9 A | 9.2A | Shielded | 20.8mOhm | - | 18MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.258" L x 0.250" W (6.56mm x 6.36mm) | 0.240" (6.10mm) |
|
|
XGL6060-333MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
2,801 |
|
规格书 |
XGL6060 | Nonstandard | Strip | Active | Molded | Metal Composite | 33 µH | ±20% | 3.6 A | 4A | Shielded | 69.5mOhm Max | - | 7MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.240" (6.10mm) |
