固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XAL5030-801MECFIXED IND 800NH 13A 5.65MOHM SM Coilcraft |
23,789 |
|
规格书 |
XAL50XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 800 nH | ±20% | 13 A | 18.5A | Shielded | 5.65mOhm Max | - | 63MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
|
XAL5030-102MECFIXED IND 1UH 11.1A 9.4MOHM SM Coilcraft |
11,695 |
|
规格书 |
XAL50XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 1 µH | ±20% | 11.1 A | 14A | Shielded | 9.4mOhm Max | - | 68MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
XGL5030-183MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
11,618 |
|
规格书 |
XGL5030 | Nonstandard | Strip | Active | Molded | Metal Composite | 18 µH | ±20% | 4 A | 3.3A | Shielded | 97.7mOhm Max | - | 11MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
|
XAL5030-122MECFIXED IND 1.2UH 10.4A 12.4MOHM Coilcraft |
5,878 |
|
规格书 |
XAL50XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 1.2 µH | ±20% | 10.4 A | 12.5A | Shielded | 12.4mOhm Max | - | 45MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
|
XAL5030-601MECFIXED IND 600NH 17.7A 4.52MOHM Coilcraft |
5,796 |
|
规格书 |
XAL50XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 600 nH | ±20% | 17.7 A | 19.8A | Shielded | 4.52mOhm Max | - | 75MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
|
XAL5030-331MECFIXED IND 330NH 19.2A 3.52MOHM Coilcraft |
5,243 |
|
规格书 |
XAL50XX | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal Composite | 330 nH | ±20% | 19.2 A | 26A | Shielded | 3.52mOhm Max | - | 108MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
XGL6020-472MECFIXED INDUCTOR 4.7UH SMD Coilcraft |
4,815 |
|
规格书 |
XGL6020 | Nonstandard | Strip | Active | Molded | Metal Composite | 4.7 µH | ±20% | 5.6 A | 6A | Shielded | 33.8mOhm Max | - | 18MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.083" (2.10mm) |
|
|
XGL5030-103MECPOWER INDUCTOR, SHIELDED, COMPOS Coilcraft |
3,907 |
|
规格书 |
XGL5030 | Nonstandard | Strip | Active | Molded | Metal Composite | 10 µH | ±20% | 5.7 A | 4.5A | Shielded | 48.4mOhm Max | - | 15MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.216" L x 0.208" W (5.48mm x 5.28mm) | 0.122" (3.10mm) |
|
|
XGL6020-682MECFIXED INDUCTOR 6.8UH SMD Coilcraft |
3,810 |
|
规格书 |
XGL6020 | Nonstandard | Strip | Active | Molded | Metal Composite | 6.8 µH | ±20% | 4.5 A | 5.1A | Shielded | 49.8mOhm Max | - | 15MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.083" (2.10mm) |
|
|
XGL6020-471MECFIXED INDUCTOR 0.47UH SMD Coilcraft |
3,665 |
|
规格书 |
XGL6020 | Nonstandard | Strip | Active | Molded | Metal Composite | 470 nH | ±20% | 15.8 A | 19.3A | Shielded | 4.2mOhm Max | - | 75MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | - | 0.264" L x 0.256" W (6.71mm x 6.51mm) | 0.083" (2.10mm) |
