固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MLF1005LR12KFIXED IND 120NH 140MA 590MOHM SM TDK Corporation |
0 |
|
规格书 |
MLF | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ferrite | 120 nH | ±10% | 140 mA | - | Shielded | 590mOhm Max | 10 @ 25MHz | 400MHz | - | -40°C ~ 85°C | 25 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
MLF1005LR27KT000FIXED IND 270NH 100MA 910MOHM SM TDK Corporation |
0 |
|
规格书 |
MLF | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ferrite | 270 nH | ±10% | 100 mA | - | Shielded | 910mOhm Max | 10 @ 25MHz | 260MHz | - | -40°C ~ 85°C | 25 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
MLF1005LR68KT000FIXED IND 680NH 40MA 550MOHM SMD TDK Corporation |
0 |
|
规格书 |
MLF | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ferrite | 680 nH | ±10% | 40 mA | - | Shielded | 550mOhm Max | 25 @ 10MHz | 150MHz | - | -40°C ~ 85°C | 10 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
|
MLF1005LR82KT000FIXED IND 820NH 35MA 590MOHM SMD TDK Corporation |
0 |
|
规格书 |
MLF | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ferrite | 820 nH | ±10% | 35 mA | - | Shielded | 590mOhm Max | 25 @ 10MHz | 130MHz | - | -40°C ~ 85°C | 10 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.022" (0.55mm) |
|
MLK1005S6N8JT000FIXED IND 6.8NH 400MA 350MOHM SM TDK Corporation |
0 |
|
规格书 |
MLK | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Non-Magnetic | 6.8 nH | ±5% | 400 mA | - | Unshielded | 350mOhm Max | 7 @ 100MHz | 5.5GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
MLK1005SR15JT000FIXED IND 150NH 80MA 5 OHM SMD TDK Corporation |
0 |
|
规格书 |
MLK | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Non-Magnetic | 150 nH | ±5% | 80 mA | - | Unshielded | 5Ohm Max | 6 @ 100MHz | 1.1GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
MLK1005SR18JT000FIXED IND 180NH 80MA 6 OHM SMD TDK Corporation |
0 |
|
规格书 |
MLK | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Non-Magnetic | 180 nH | ±5% | 80 mA | - | Unshielded | 6Ohm Max | 6 @ 100MHz | 1.1GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
NLCV25T-6R8M-EFRFIXED IND 6.8UH 390MA 1.104 OHM TDK Corporation |
0 |
|
规格书 |
NLCV-EF | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±20% | 390 mA | - | Unshielded | 1.104Ohm Max | 10 @ 7.96MHz | 38MHz | - | -40°C ~ 105°C | 7.96 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.075" (1.90mm) |
|
MLK1005S56NJT000FIXED IND 56NH 200MA 1.3 OHM SMD TDK Corporation |
0 |
|
规格书 |
MLK | 0402 (1005 Metric) | Tape & Reel (TR) | Last Time Buy | Multilayer | Non-Magnetic | 56 nH | ±5% | 200 mA | - | Unshielded | 1.3Ohm Max | 6 @ 100MHz | 1.5GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
NLV32T-027J-PFFIXED IND 27NH 450MA 220MOHM SMD TDK Corporation |
75 |
|
规格书 |
NLV-PF | 1210 (3225 Metric) | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 27 nH | ±5% | 450 mA | - | Unshielded | 220mOhm Max | 23 @ 100MHz | 1.5GHz | - | -40°C ~ 105°C | 100 MHz | - | Surface Mount | 1210 | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.094" (2.40mm) |
