上传BOM
固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SWPA8040S1R5NTFIXED IND 1.5UH 5.65A 13MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.5 µH | ±30% | 5.65 A | 8.15A | Shielded | 13mOhm Max | - | 67MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S270MTFIXED IND 27UH 2A 101 MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 27 µH | ±20% | 2 A | 2.15A | Shielded | 101mOhm Max | - | 9.2MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S221MTFIXED IND 220UH 800MA 779MOHM SM Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±20% | 800 mA | 850mA | Shielded | 779mOhm Max | - | 3.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S181MTFIXED IND 180UH 830MA 676MOHM SM Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 180 µH | ±20% | 830 mA | 950mA | Shielded | 676mOhm Max | - | 3.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S5R6NTFIXED IND 5.6UH 3.85A 27MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 5.6 µH | ±30% | 3.85 A | 6A | Shielded | 27mOhm Max | - | 24MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S470MTFIXED IND 47UH 1.55A 177MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 1.55 A | 1.75A | Shielded | 177mOhm Max | - | 6.4MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S180MTFIXED IND 18UH 2.4A 69 MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 18 µH | ±20% | 2.4 A | 2.7A | Shielded | 69mOhm Max | - | 11MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S510MTFIXED IND 51UH 1.5A 185MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 51 µH | ±20% | 1.5 A | 1.7A | Shielded | 185mOhm Max | - | 6.4MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S430MTFIXED IND 43UH 1.65A 147MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 43 µH | ±20% | 1.65 A | 1.9A | Shielded | 147mOhm Max | - | 7.8MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
|
|
SWPA8040S151MTFIXED IND 150UH 850MA 533MOHM SM Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
SWPA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±20% | 850 mA | 1.1A | Shielded | 533mOhm Max | - | 3.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.165" (4.20mm) |
