上传BOM
固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MWSD1005C5N7DTM81FIXED IND 5.7NH 1.77A 40MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 5.7 nH | ±0.5nH | 1.77 A | - | Unshielded | 40mOhm Max | 30 @ 250MHz | 8GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C5N5JTM81FIXED IND 5.5NH 1.77A 40MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 5.5 nH | ±5% | 1.77 A | - | Unshielded | 40mOhm Max | 35 @ 250MHz | 8GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C5N6JTFIXED IND 5.6NH 710MA 78MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 5.6 nH | ±5% | 710 mA | - | Unshielded | 78mOhm Max | 25 @ 250MHz | 6GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C36NKTM81FIXED IND 36NH 540MA 431MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M8X | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 36 nH | ±10% | 540 mA | - | Unshielded | 431mOhm Max | 30 @ 250MHz | 3.5GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C39NKTM81FIXED IND 39NH 530MA 456MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M8X | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 39 nH | ±10% | 530 mA | - | Unshielded | 456mOhm Max | 28 @ 250MHz | 3.4GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C3N7DTM81FIXED IND 3.7NH 1.95A 30MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 3.7 nH | ±0.5nH | 1.95 A | - | Unshielded | 30mOhm Max | 35 @ 250MHz | 10GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
MWSD1005CHR22HSTFFIXED IND 220NH 160MA 3.5OHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-CH | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 220 nH | ±3% | 160 mA | - | Unshielded | 3.5Ohm Max | 32 @ 250MHz | - | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.028" (0.70mm) |
|
MWSD1005C1N5BTM01FIXED IND 1.5NH 1A 30 MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 1.5 nH | ±0.1nH | 1 A | - | Unshielded | 30mOhm Max | 10 @ 250MHz | 6GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C6N4HTM81FIXED IND 6.4NH 1.38A 65MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 6.4 nH | ±3% | 1.38 A | - | Unshielded | 65mOhm Max | 33 @ 250MHz | 7GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
|
|
MWSD1005C13NKTM81FIXED IND 13NH 1.24A 93MOHM SMD Shenzhen Sunlord Electronics Co., Ltd. |
0 |
|
规格书 |
MWSD-C-M8X | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 13 nH | ±10% | 1.24 A | - | Unshielded | 93mOhm Max | 30 @ 250MHz | 5.2GHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0402 | 0.043" L x 0.024" W (1.10mm x 0.60mm) | 0.026" (0.65mm) |
