固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CDR63BNP-390LCFIXED IND 39UH 530MA 470MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR63B | Nonstandard | Tape & Reel (TR) | Obsolete | - | - | 39 µH | ±15% | 530 mA | - | Shielded | 470mOhm Max | - | 17MHz | - | -40°C ~ 100°C | - | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.138" (3.50mm) |
|
|
CDR63BNP-470LCFIXED IND 47UH 500MA 510MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR63B | Nonstandard | Tape & Reel (TR) | Obsolete | - | - | 47 µH | ±15% | 500 mA | - | Shielded | 510mOhm Max | - | 15.3MHz | - | -40°C ~ 100°C | - | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.138" (3.50mm) |
|
|
CDR63BNP-560LCFIXED IND 56UH 460MA 720MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR63B | Nonstandard | Tape & Reel (TR) | Obsolete | - | - | 56 µH | ±15% | 460 mA | - | Shielded | 720mOhm Max | - | 14.1MHz | - | -40°C ~ 100°C | - | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.138" (3.50mm) |
|
CDR74BNP-100MCFIXED IND 10UH 1.65A 70 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 10 µH | ±20% | 1.65 A | - | Shielded | 70mOhm Max | - | 26.3MHz | - | -25°C ~ 80°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-101KCFIXED IND 100UH 550MA 490MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 100 µH | ±10% | 550 mA | - | Shielded | 490mOhm Max | - | 8.3MHz | - | -25°C ~ 80°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-120MCFIXED IND 12UH 1.57A 70 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 12 µH | ±20% | 1.57 A | - | Shielded | 70mOhm Max | - | 25.1MHz | - | -25°C ~ 80°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-121KCFIXED IND 120UH 490MA 680MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 120 µH | ±10% | 490 mA | - | Shielded | 680mOhm Max | - | 7.3MHz | - | -25°C ~ 80°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-150MCFIXED IND 15UH 1.39A 80 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 15 µH | ±20% | 1.39 A | - | Shielded | 80mOhm Max | - | 19.9MHz | - | -25°C ~ 80°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-151KCFIXED IND 150UH 440MA 940MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 150 µH | ±10% | 440 mA | - | Shielded | 940mOhm Max | - | 6.4MHz | - | -25°C ~ 80°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
|
|
CDR74BNP-180MCFIXED IND 18UH 1.29A 100MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR74B | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 18 µH | ±20% | 1.29 A | - | Shielded | 100mOhm Max | - | 19.3MHz | - | -25°C ~ 80°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.193" (4.90mm) |
