固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CDR105NP-221MCFIXED IND 220UH 540MA 690MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CDR105 | Nonstandard | Tape & Reel (TR) | Obsolete | - | - | 220 µH | -15%, +20% | 540 mA | - | Shielded | 690mOhm Max | - | 5.2MHz | - | -40°C ~ 100°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.362" W (10.00mm x 9.20mm) | 0.217" (5.50mm) |
|
|
CDR105NP-560MCFIXED IND 56UH 1.07A 190MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDR105 | Nonstandard | Tape & Reel (TR) | Active | - | - | 56 µH | -15%, +20% | 1.07 A | - | Shielded | 190mOhm Max | - | 12MHz | - | -40°C ~ 100°C | 2.52 MHz | - | Surface Mount | - | 0.394" L x 0.362" W (10.00mm x 9.20mm) | 0.217" (5.50mm) |
|
CDRH8D28NP-7R3NCFIXED IND 7.3UH 3.4A 39 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDRH8D28 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 7.3 µH | ±30% | 3.4 A | 2.8A | Shielded | 39mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.118" (3.00mm) |
|
CD73NP-100MCFIXED IND 10UH 1.44A 80.3MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CD73 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 10 µH | ±20% | 1.44 A | - | Unshielded | 80.3mOhm Max | - | - | - | -30°C ~ 100°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.157" (4.00mm) |
|
|
CD73NP-151KCFIXED IND 150UH 400MA 755MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CD73 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 150 µH | ±10% | 400 mA | - | Unshielded | 755mOhm Max | - | - | - | -30°C ~ 100°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.157" (4.00mm) |
|
CDRH8D28HPNP-3R3NCFIXED IND 3.3UH 3.8A 35 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDRH8D28/HP | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 3.3 µH | ±30% | 3.8 A | 6.5A | Shielded | 35mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.118" (3.00mm) |
|
CDRH8D28NP-1R0NCFIXED IND 1UH 7A 11 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDRH8D28 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1 µH | ±30% | 7 A | 6.5A | Shielded | 11mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.118" (3.00mm) |
|
|
CDRH8D28NP-2R5NCFIXED IND 2.5UH 6.4A 15.6MOHM SM Sumida America Components Inc. |
0 |
|
规格书 |
CDRH8D28 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 2.5 µH | ±30% | 6.4 A | 4.5A | Shielded | 15.6mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.118" (3.00mm) |
|
|
CDRH8D28NP-470NCFIXED IND 47UH 1.3A 195 MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDRH8D28 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 47 µH | ±30% | 1.3 A | 1.15A | Shielded | 195mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | 0.118" (3.00mm) |
|
CDRH2D14NP-100NCFIXED IND 10UH 760MA 294MOHM SMD Sumida America Components Inc. |
0 |
|
规格书 |
CDRH2D14 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 10 µH | ±30% | 760 mA | 700mA | Shielded | 294mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.061" (1.55mm) |
