上传BOM
固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RCP1317NP-182LFIXED IND 1.8MH 580MA 2 OHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 1.8 mH | ±15% | 580 mA | 680mA | Shielded | 2Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-221LFIXED IND 220UH 1.6A 278 MOHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 220 µH | ±15% | 1.6 A | 1.9A | Shielded | 278mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-222LFIXED IND 2.2MH 520MA 2.28OHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 2.2 mH | ±15% | 520 mA | 620mA | Shielded | 2.28Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-271LFIXED IND 270UH 1.55A 330MOHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 270 µH | ±15% | 1.55 A | 1.7A | Shielded | 330mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-272LFIXED IND 2.7MH 480MA 3.07OHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 2.7 mH | ±15% | 480 mA | 580mA | Shielded | 3.07Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-330MFIXED IND 33UH 3.6A 58 MOHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 33 µH | ±20% | 3.6 A | 4.8A | Shielded | 58mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-331LFIXED IND 330UH 1.5A 360 MOHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 330 µH | ±15% | 1.5 A | 1.6A | Shielded | 360mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-332LFIXED IND 3.3MH 450MA 3.31OHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 3.3 mH | ±15% | 450 mA | 510mA | Shielded | 3.31Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-391LFIXED IND 390UH 1.3A 440 MOHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | - | Ferrite | 390 µH | ±15% | 1.3 A | 1.45A | Shielded | 440mOhm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
|
|
RCP1317NP-392LFIXED IND 3.9MH 420MA 4.52OHM TH Sumida America Components Inc. |
0 |
|
规格书 |
RCP1317 | Radial, Vertical Cylinder | Bulk | Active | - | Ferrite | 3.9 mH | ±15% | 420 mA | 470mA | Shielded | 4.52Ohm Max | - | - | - | -40°C ~ 100°C | 1 kHz | - | Through Hole | - | 0.531" Dia (13.50mm) | 0.689" (17.50mm) |
