固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ASPIAIG-H8540-4R7M-TFIXED IND 4.7UH 4.2A 27.6MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-H8540 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 4.7 µH | ±20% | 4.2 A | 12.5A | Shielded | 27.6mOhm | - | 19MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.346" L x 0.335" W (8.80mm x 8.50mm) | 0.157" (4.00mm) |
|
|
ASPIAIG-H8540-100M-TFIXED IND 10UH 3.5A 53.9MOHM SMD Abracon LLC |
0 |
|
规格书 |
ASPIAIG-H8540 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 10 µH | ±20% | 3.5 A | 8A | Shielded | 53.9mOhm | - | 12MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.346" L x 0.335" W (8.80mm x 8.50mm) | 0.157" (4.00mm) |
|
ATCA-06-221M-HFIXED IND 220UH 2A 121 MOHM TH Abracon LLC |
0 |
|
规格书 |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 220 µH | ±20% | 2 A | - | Unshielded | 121mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.260" Dia (32.00mm) | 0.630" (16.00mm) |
|
ATCA-06-221M-VFIXED IND 220UH 2A 121 MOHM TH Abracon LLC |
0 |
|
规格书 |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 220 µH | ±20% | 2 A | - | Unshielded | 121mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.260" L x 0.630" W (32.00mm x 16.00mm) | - |
|
AMDLA1707Q-680MTIND 68UH 8.0A 76MOHM Abracon LLC |
0 |
|
规格书 |
AMDLA1707Q | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 68 µH | ±20% | 8 A | 8.5A | Shielded | 76mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.701" L x 0.665" W (17.80mm x 16.90mm) | 0.276" (7.00mm) |
|
ATCA-04-431M-HFIXED IND 430UH 2A 150 MOHM TH Abracon LLC |
0 |
|
规格书 |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 430 µH | ±20% | 2 A | - | Unshielded | 150mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.063" Dia (27.00mm) | 0.531" (13.50mm) |
|
ATCA-04-431M-VFIXED IND 430UH 2A 150 MOHM TH Abracon LLC |
0 |
|
规格书 |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 430 µH | ±20% | 2 A | - | Unshielded | 150mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.063" L x 0.531" W (27.00mm x 13.50mm) | - |
|
ASPIAIG-Q1010-8R2M-TFIXED IND 8.2UH 17.1A 12.4 MOHM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-Q1010 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 17.1 A | 16.3A | Shielded | 12.4mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.469" L x 0.433" W (11.90mm x 11.00mm) | 0.394" (10.00mm) |
|
|
ASPIAIG-Q1010-5R6M-TFIXED IND 5.6UH 21.2A 7.2MOHM SM Abracon LLC |
0 |
|
规格书 |
ASPIAIG-Q1010 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 21.2 A | 19.6A | Shielded | 7.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.469" L x 0.433" W (11.90mm x 11.00mm) | 0.394" (10.00mm) |
|
ATCA-05-900M-HFIXED IND 90UH 5A 34 MOHM TH Abracon LLC |
0 |
|
规格书 |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 90 µH | ±20% | 5 A | - | Unshielded | 34mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.181" Dia (30.00mm) | 0.669" (17.00mm) |
