固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
27683CFIXED IND 68UH 420MA 900MOHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | ±20% | 420 mA | - | Unshielded | 900mOhm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27104CFIXED IND 100UH 350MA 1.3OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | ±20% | 350 mA | - | Unshielded | 1.3Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27154CFIXED IND 150UH 280MA 2 OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 150 µH | ±20% | 280 mA | - | Unshielded | 2Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27224CFIXED IND 220UH 240MA 3 OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 220 µH | ±20% | 240 mA | - | Unshielded | 3Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27334CFIXED IND 330UH 190MA 4.5OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 330 µH | ±20% | 190 mA | - | Unshielded | 4.5Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27474CFIXED IND 470UH 160MA 6.5OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 470 µH | ±20% | 160 mA | - | Unshielded | 6.5Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27684CFIXED IND 680UH 140MA 8.5OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 680 µH | ±20% | 140 mA | - | Unshielded | 8.5Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
|
27105CFIXED IND 1MH 110MA 14 OHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
2700 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 mH | ±20% | 110 mA | - | Unshielded | 14Ohm Max | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.354" L x 0.303" W (9.00mm x 7.70mm) | 0.065" (1.65mm) |
|
15684CFIXED IND 680UH 1.12A 574MOHM TH Murata Power Solutions Inc. |
0 |
|
规格书 |
1500 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 680 µH | ±10% | 1.12 A | - | Unshielded | 574mOhm Max | 86 @ 25kHz | 1MHz | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.661" Dia (16.80mm) | 0.839" (21.30mm) |
|
30800ACFIXED IND 80NH 37A 0.35 MOHM SMD Murata Power Solutions Inc. |
0 |
|
规格书 |
3000A | 2-SMD | Tape & Reel (TR) | Active | Wirewound | - | 80 nH | ±20% | 37 A | 47A | Shielded | 0.35mOhm Max | - | - | - | -40°C ~ 130°C | 1 MHz | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 0.195" (4.96mm) |
