固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LRC0603CS1N0GV001TFIXED IND 1NH 300MA 100 MOHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 1 nH | ±0.3nH | 300 mA | - | Unshielded | 100mOhm Max | 8 @ 100MHz | 17GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.037" (0.95mm) |
|
|
LRC0402CS4N3GV001TFIXED IND 4.3NH 300MA 240MOHM SM Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 4.3 nH | ±0.3nH | 300 mA | - | Unshielded | 240mOhm Max | 8 @ 100MHz | 6GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
LRC0201BS1N5GV001TFIXED IND 1.5NH 300MA 180MOHM SM Johanson Technology Inc. |
0 |
|
规格书 |
- | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | 1.5 nH | ±0.3nH | 300 mA | - | Unshielded | 180mOhm Max | 4 @ 100MHz | 13GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0201 (0603 Metric) | 0.024" L x 0.012" W (0.60mm x 0.30mm) | 0.013" (0.33mm) |
|
|
LRW0402WJ27NGG001TFIXED IND 27NH 400MA 298MOHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 27 nH | ±5% | 400 mA | - | Unshielded | 298mOhm Max | 55 @ 900MHz | 2.5GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.022" W (1.00mm x 0.55mm) | 0.024" (0.60mm) |
.jpg)
|
L-07C11NKV6TFIXED IND 11NH 250MA SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 11 nH | ±10% | 250 mA | - | Unshielded | - | 8 @ 100MHz | - | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
L-07C40NJV4TFIXED IND 40NH SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 40 nH | ±5% | - | - | Unshielded | - | 8 @ 100MHz | - | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
L-07C40NJV6TFIXED IND 40NH SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 40 nH | ±5% | - | - | Unshielded | - | 8 @ 100MHz | - | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
L-07C43NJV4TFIXED IND 43NH 150MA 1.3 OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 43 nH | ±5% | 150 mA | - | Unshielded | 1.3Ohm Max | 8 @ 100MHz | 1.3GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
L-07C47NJV4TFIXED IND 47NH 150MA 1.3 OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 47 nH | ±5% | 150 mA | - | Unshielded | 1.3Ohm Max | 8 @ 100MHz | 1.2GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
L-07C56NJV4TFIXED IND 56NH 150MA 2 OHM SMD Johanson Technology Inc. |
0 |
|
规格书 |
- | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | Ceramic | 56 nH | ±5% | 150 mA | - | Unshielded | 2Ohm Max | 8 @ 100MHz | 1.1GHz | - | -55°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
