场效应晶体管（FETs）、MOSFETs
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IXFH16N50P3MOSFET N-CH 500V 16A TO247AD |
290 |
|
规格书 |
HiPerFET™, Polar3™ | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 16A (Tc) | 10V | 360mOhm @ 8A, 10V | 5V @ 2.5mA | 29 nC @ 10 V | ±30V | 1515 pF @ 25 V | - | 330W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
TK16G60W,RVQMOSFET N CH 600V 15.8A D2PAK |
984 |
|
规格书 |
DTMOSIV | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 15.8A (Ta) | 10V | 190mOhm @ 7.9A, 10V | 3.7V @ 790µA | 38 nC @ 10 V | ±30V | 1350 pF @ 300 V | - | 130W (Tc) | 150°C (TJ) | - | - | Surface Mount | D2PAK |
|
STW35N65DM2MOSFET N-CH 650V 32A TO247 |
816 |
|
规格书 |
MDmesh™ DM2 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 32A (Tc) | 10V | 110mOhm @ 16A, 10V | 5V @ 250µA | 56.3 nC @ 10 V | ±25V | 2540 pF @ 100 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
NVHL095N65S3FSF3 FRFET AUTO 95MOHM TO-247 |
418 |
|
规格书 |
SuperFET® III, FRFET® | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 36A (Tc) | 10V | 95mOhm @ 18A, 10V | 5V @ 860µA | 66 nC @ 10 V | ±30V | 3020 pF @ 400 V | - | 272W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
SIHB24N65E-GE3MOSFET N-CH 650V 24A D2PAK |
1,868 |
|
规格书 |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 145mOhm @ 12A, 10V | 4V @ 250µA | 122 nC @ 10 V | ±30V | 2740 pF @ 100 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
|
IPTG018N10NM5ATMA1TRENCH >=100V PG-HSOG-8 |
1,700 |
|
规格书 |
OptiMOS™ | 8-PowerSMD, Gull Wing | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 32A (Ta), 273A Tc) | 6V, 10V | 1.8mOhm @ 150A, 10V | 3.8V @ 202µA | 152 nC @ 10 V | ±20V | 11000 pF @ 50 V | - | 3.8W (Ta), 273W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PG-HSOG-8-1 |
|
|
NVHL095N65S3HFSUPERFER3 FRFET AUTOMOTIVE 95MOH |
450 |
|
规格书 |
SuperFET® III, FRFET® | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 36A (Tc) | 10V | 95mOhm @ 18A, 10V | 5V @ 860µA | 66 nC @ 10 V | ±30V | 3105 pF @ 400 V | - | 272W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
|
IPB65R110CFDATMA2MOSFET N-CH 650V 31.2A TO263-3 |
1,960 |
|
规格书 |
CoolMOS™ CFD2 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 31.2A (Tc) | 10V | 110mOhm @ 12.7A, 10V | 4.5V @ 1.3mA | 118 nC @ 10 V | ±20V | 3240 pF @ 100 V | - | 277.8W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PG-TO263-3 |
|
|
SIHP085N60EF-GE3EF SERIES POWER MOSFET WITH FAST |
1,995 |
|
规格书 |
EF | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 34A (Tc) | 10V | 84mOhm @ 17A, 10V | 5V @ 250µA | 63 nC @ 10 V | ±30V | 2733 pF @ 100 V | - | 184W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
|
IMWH170R450M1XKSA1IMWH170R450M1XKSA1 |
252 |
|
- |
CoolSiC™ | TO-247-3 | Tray | Active | N-Channel | SiCFET (Silicon Carbide) | 1700 V | 10A (Tj) | 12V, 15V | 390mOhm @ 2A, 15V | 5.7V @ 2.6mA | 11.7 nC @ 12 V | 15V, 12V | 506 pF @ 1000 V | - | 111W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | PG-TO247-3-U04 |
|
SIHF30N60E-GE3MOSFET N-CH 600V 29A TO220 |
2,975 |
|
规格书 |
E | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 29A (Tc) | 10V | 125mOhm @ 15A, 10V | 4V @ 250µA | 130 nC @ 10 V | ±30V | 2600 pF @ 100 V | - | 37W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | - |
|
|
MCBS260N10Y-TPN-CHANNEL MOSFET,TO-263-7 |
1,508 |
|
规格书 |
- | TO-263-7, D2PAK (6 Leads + Tab), TO-263CB | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 260A (Tc) | 10V | 1.8mOhm @ 30A, 10V | 4V @ 250µA | 161 nC @ 10 V | ±20V | 10589 pF @ 25 V | - | 375W (Tj) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263-7 |
|
SIHG24N65E-GE3MOSFET N-CH 650V 24A TO247AC |
610 |
|
规格书 |
- | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 145mOhm @ 12A, 10V | 4V @ 250µA | 122 nC @ 10 V | ±30V | 2740 pF @ 100 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AC |
|
|
CDF56G7032N TR13 PBFREESURFACE MOUNT MOSFET |
2,500 |
|
- |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 700 V | 18A (Tc) | 6V | 140mOhm @ 5A, 6V | 2.5V @ 17.2mA | 3.5 nC @ 6 V | +7V, -6V | 125 pF @ 400 V | - | 1.1W (Ta), 113W (Tc) | -55°C ~ 155°C (TJ) | - | - | Surface Mount, Wettable Flank | 8-DFN (5x6) |
|
|
TK095N65Z5,S1F(S650V DTMOS6-HIGH SPEED DIODE |
195 |
|
- |
DTMOSVI | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 29A (Ta) | 10V | 95mOhm @ 14.5A, 10V | 4.5V @ 1.27mA | 50 nC @ 10 V | ±30V | 2880 pF @ 300 V | - | 230W (Tc) | 150°C | - | - | Through Hole | TO-247 |
|
|
XP10NA1R5TLMOSFET N-CH 100V 300A TOLL |
987 |
|
规格书 |
XP10NA1R5 | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 300A (Tc) | 10V | 1.5mOhm @ 100A, 10V | 4V @ 250µA | 304 nC @ 10 V | ±20V | 16960 pF @ 80 V | - | 3.75W (Ta), 333W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TOLL |
|
|
MSC180SMA120SDT/RMOSFET SIC 1200 V 180 MOHM TO-26 |
773 |
|
规格书 |
mSiC™ | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Active | N-Channel | SiCFET (Silicon Carbide) | 1200 V | 21A (Tc) | 18V, 20V | 225mOhm @ 8A, 20V | 5V @ 500µA | 36 nC @ 20 V | +23V, -10V | 481 pF @ 1.2 kV | - | 146W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263-7 |
|
|
SIHF085N60EF-GE3EF SERIES POWER MOSFET TO-220 FU |
1,000 |
|
规格书 |
EF | TO-220-3 Full Pack | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Tc) | 10V | 84mOhm @ 17A, 10V | 5V @ 250µA | 63 nC @ 10 V | ±30V | 2733 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 Full Pack |
|
|
IPW95R130PFD7XKSA1HIGH POWER_NEW |
314 |
|
规格书 |
CoolMOS™ | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 950 V | 36.5A | 10V | - | - | 141 nC @ 10 V | ±20V | - | - | 227W | -55°C ~ 150°C | - | - | Through Hole | PG-TO247-3-41 |
|
|
NTMTS002N08MCPTNG 80V IN CEBU PQFN88 |
2,948 |
|
规格书 |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 29A (Ta), 229A (Tc) | 6V, 10V | 2mOhm @ 90A, 10V | 4V @ 540µA | 125 nC @ 10 V | ±20V | 8900 pF @ 40 V | - | 3.3W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-DFNW (8.3x8.4) |
