上传BOM
穿心电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 电容 | 容差 | 额定电压 | 电流 | 直流电阻 (DCR)（最大值） | 工作温度 | 插入损耗 | 温度系数 | 额定值 | 安装类型 | 尺寸 / 尺寸 | 高度（最大值） | 螺纹尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
-Series.jpg)
|
SFJEL1K00223MX1CAP FEEDTHRU 0.022UF 1KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.022 µF | ±20% | 1000V (1kV) | 15 A | - | -55°C ~ 125°C | 48dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL1K00333MX1CAP FEEDTHRU 0.033UF 1KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.033 µF | ±20% | 1000V (1kV) | 15 A | - | -55°C ~ 125°C | 50dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL5000154MX1CAP FEEDTHRU 0.15UF 500V AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.15 µF | ±20% | 500V | 15 A | - | -55°C ~ 125°C | 62dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC2K00681MC0CAP FEEDTHRU 680PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 680 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 19dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL1K00473MX0CAP FEEDTHRU 0.047UF 1KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.047 µF | ±20% | 1000V (1kV) | 15 A | - | -55°C ~ 125°C | 51dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL5000224MX0CAP FEEDTHRU 0.22UF 500V AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.22 µF | ±20% | 500V | 15 A | - | -55°C ~ 125°C | 66dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC2K00102MC0CAP FEEDTHRU 1000PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 1000 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 23dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL3K00221MC0CAP FEEDTHRU 220PF 3KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 220 pF | ±20% | 3000V (3kV) | 15 A | - | -55°C ~ 125°C | 12dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC2K00681MC1CAP FEEDTHRU 680PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 680 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 19dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL1K00473MX1CAP FEEDTHRU 0.047UF 1KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.047 µF | ±20% | 1000V (1kV) | 15 A | - | -55°C ~ 125°C | 51dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL5000224MX1CAP FEEDTHRU 0.22UF 500V AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.22 µF | ±20% | 500V | 15 A | - | -55°C ~ 125°C | 66dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC3K00151MC0CAP FEEDTHRU 150PF 3KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 150 pF | ±20% | 3000V (3kV) | 15 A | - | -55°C ~ 125°C | 7dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL2K00331MC0CAP FEEDTHRU 330PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 330 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 16dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL3K00101MC0CAP FEEDTHRU 100PF 3KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 100 pF | ±20% | 3000V (3kV) | 15 A | - | -55°C ~ 125°C | 7dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC2K00102MC1CAP FEEDTHRU 1000PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 1000 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 23dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL3K00221MC1CAP FEEDTHRU 220PF 3KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 220 pF | ±20% | 3000V (3kV) | 15 A | - | -55°C ~ 125°C | 12dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL1K00683MX0CAP FEEDTHRU 0.068UF 1KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 0.068 µF | ±20% | 1000V (1kV) | 15 A | - | -55°C ~ 125°C | 55dB @ 100MHz | X7R | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL2K00471MC0CAP FEEDTHRU 470PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 470 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 19dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEC3K00151MC1CAP FEEDTHRU 150PF 3KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 150 pF | ±20% | 3000V (3kV) | 15 A | - | -55°C ~ 125°C | 7dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
|
|
SFJEL2K00331MC1CAP FEEDTHRU 330PF 2KV AXIAL |
0 |
|
规格书 |
SFJE | Axial, Bushing | Bulk | Obsolete | 330 pF | ±20% | 2000V (2kV) | 15 A | - | -55°C ~ 125°C | 16dB @ 100MHz | C0G, NP0 | - | - | 0.386" Dia x 0.370" L (9.80mm x 9.40mm) | - | 1/4-28 |
