铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ESRD8R2M16RCAP ALUM POLY 8.2UF 20% 16V SMD Cornell Dubilier Knowles |
494 |
|
规格书 |
ESRD | Tape & Reel (TR) | Obsolete | Polymer | 8.2 µF | ±20% | 16 V | 45mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | Bypass, Decoupling | - | - | 1.3 A @ 100 kHz | - | - | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.071" (1.80mm) | 0.287" L x 0.169" W (7.30mm x 4.30mm) | Surface Mount |
|
PPC802M016FG2SAACAP ALUM POLY 8000UF 20% 16V CMD Cornell Dubilier Knowles |
5 |
|
规格书 |
PPC | Box | Obsolete | Polymer | 8000 µF | ±20% | 16 V | 6mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 16 A @ 120 Hz | 18 A @ 20 kHz | - | - | 6.250" L x 5.000" W (158.75mm x 127.00mm) | 0.039" (1.00mm) | - | Chassis Mount |
|
PPC123M010FG2SAACAP ALUM POLY 12000UF 20% 10V Cornell Dubilier Knowles |
2 |
|
规格书 |
PPC | Box | Obsolete | Polymer | 12000 µF | ±20% | 10 V | 6mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 16 A @ 120 Hz | 18 A @ 20 kHz | - | - | 6.250" L x 5.000" W (158.75mm x 127.00mm) | 0.039" (1.00mm) | - | Chassis Mount |
|
|
PPC203M6R3FG2SAACAP ALUM POLY 20000UF 20% 6.3V Cornell Dubilier Knowles |
2 |
|
规格书 |
PPC | Box | Obsolete | Polymer | 20000 µF | ±20% | 6.3 V | 6mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 16 A @ 120 Hz | 18 A @ 20 kHz | - | - | 6.250" L x 5.000" W (158.75mm x 127.00mm) | 0.039" (1.00mm) | - | Chassis Mount |
|
476AVG100MGBJCAP ALUM POLY 47UF 20% 100V TH Cornell Dubilier Knowles |
7 |
|
规格书 |
AVG | Bulk | Active | Polymer | 47 µF | ±20% | 100 V | 38mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 105 mA @ 120 Hz | 2.1 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.532" (13.50mm) | - | Through Hole |
|
227ALG050MGBJCAP ALUM POLY 220UF 20% 50V TH Cornell Dubilier Knowles |
0 |
|
规格书 |
ALG | Bulk | Active | Polymer | 220 µF | ±20% | 50 V | 25mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | Automotive | - | 155 mA @ 120 Hz | 3.1 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.532" (13.50mm) | - | Through Hole |
-V.jpg)
|
HZA107M050G24VT-FCAP ALUMHYB 100UF 20% 50V SMD Cornell Dubilier Knowles |
11 |
|
规格书 |
HZA_V | Tape & Reel (TR) | Active | Hybrid | 100 µF | ±20% | 50 V | 28mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 200 mA @ 120 Hz | 2 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.413" (10.50mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
HZC686M035X16T-FCAP ALUM HYBRID 68UF 20% 35V SMD Cornell Dubilier Knowles |
0 |
|
规格书 |
HZC | Tape & Reel (TR) | Active | Hybrid | 68 µF | ±20% | 35 V | 35mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 140 mA @ 120 Hz | 1.4 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.315" (8.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
HZC107M050G24VT-FCAP ALUMHYB 100UF 20% 50V SMD Cornell Dubilier Knowles |
0 |
|
规格书 |
HZC_V | Tape & Reel (TR) | Active | Hybrid | 100 µF | ±20% | 50 V | 28mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive, Bypass, Decoupling | - | 160 mA @ 120 Hz | 1.6 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.413" (10.50mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
567UER6R3MFFCAP ALUM POLY 560UF 20% 6.3V TH Cornell Dubilier Knowles |
0 |
|
规格书 |
UER | Bulk | Active | Polymer | 560 µF | ±20% | 6.3 V | 8mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | Decoupling | - | 240 mA @ 120 Hz | 4.8 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | - | Through Hole |
