铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RNU1E221MCNASQCAP ALUM POLY 220UF 20% 25V TH Nichicon |
0 |
|
规格书 |
FPCAP, RNU | Tape & Box (TB) | Active | Polymer | 220 µF | ±20% | 25 V | 16mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 465 mA @ 120 Hz | 4.65 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.512" (13.00mm) | - | Through Hole |
|
|
RHA1C471MCNASQGSCAP ALUM POLY 470UF 20% 16V SMD Nichicon |
0 |
|
规格书 |
FPCAP, RHA | Tape & Reel (TR) | Active | Polymer | 470 µF | ±20% | 16 V | 16mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 407 mA @ 120 Hz | 4.07 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.354" (9.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
RPS0J181MCN1GSCAP ALUM POLY 180UF 20% 6.3V SMD Nichicon |
0 |
|
规格书 |
FPCAP, RPS | Tape & Reel (TR) | Active | Polymer | 180 µF | ±20% | 6.3 V | 30mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 260 mA @ 120 Hz | 2.6 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.264" (6.70mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
RHS0J391MCN1GSCAP ALUM POLY 390UF 20% 6.3V SMD Nichicon |
0 |
|
规格书 |
FPCAP, RHS | Tape & Reel (TR) | Active | Polymer | 390 µF | ±20% | 6.3 V | 18mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 320 mA @ 120 Hz | 3.2 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.264" (6.70mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
PLF0G681MDO1TDCAP ALUM POLY 680UF 20% 4V TH Nichicon |
0 |
|
规格书 |
PLF | Cut Tape (CT) | Active | Polymer | 680 µF | ±20% | 4 V | 6mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 6.2 A @ 100 kHz | - | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | - | Through Hole |
|
|
PCR1H121MCSDNAGSCAP ALUM POLY 330UF 20% 6.3V SMD Nichicon |
0 |
|
- |
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RNU1D561MDN1CAP ALUM 100UF 63V Nichicon |
0 |
|
规格书 |
- | Tape & Box (TB) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
RNU1V121MDNASQCAP ALUM POLY 120UF 20% 35V TH Nichicon |
0 |
|
规格书 |
FPCAP, RNU | Tape & Box (TB) | Active | Polymer | 120 µF | ±20% | 35 V | 18mOhm | 5000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 440 mA @ 120 Hz | 4.4 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole |
|
|
PLG0J152MDO1TDCAP ALUM POLY 1500UF 20% 6.3V TH Nichicon |
0 |
|
规格书 |
PLG | Tape & Box (TB) | Active | Polymer | 1500 µF | ±20% | 6.3 V | 9mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | 315 mA @ 120 Hz | 6.3 A @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.532" (13.50mm) | - | Through Hole |
|
PCJ0E272MCL1GSCAP ALUM POLY 2700UF 20% 2.5V Nichicon |
0 |
|
规格书 |
PCJ | Tape & Reel (TR) | Active | Polymer | 2700 µF | ±20% | 2.5 V | 9mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | General Purpose | - | - | 5.8 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
