交流直流桌面、墙式电源适配器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 使用区域 | 形式 | 输入类型 | 电压 - 输入 | 电压 - 输出 | 电流 - 输出（最大值） | 功率（瓦特） | 空载功耗 | 极化 | 应用 | 效率 | 工作温度 | 输出连接器 | 电线长度 | 输入连接器 | 特性 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DT200Z-3AC/DC DESKTOP ADAPTER 18V 180W |
0 |
|
规格书 |
DT200Z (200W) | Box | Active | International | Desktop (Class I) | Cord (Sold Separately) | 90 ~ 264 VAC | 18V | 10A | 180 W | 500mW (Max) | - | ITE (Commercial) | 87% | -20°C ~ 60°C | Rectangular, 6 Position | 72" (1.83m) | IEC 320-C14 | - | 8.27" L x 4.06" W x 2.05" H (210.0mm x 103.0mm x 52.0mm) | - |
|
|
DT200Z-6AC/DC DESKTOP ADAPTER 24V 202W |
0 |
|
规格书 |
DT200Z (200W) | Box | Active | International | Desktop (Class I) | Cord (Sold Separately) | 90 ~ 264 VAC | 24V | 8.4A | 202 W | 500mW (Max) | - | ITE (Commercial) | 87% | -20°C ~ 60°C | Rectangular, 6 Position | 72" (1.83m) | IEC 320-C14 | - | 8.27" L x 4.06" W x 2.05" H (210.0mm x 103.0mm x 52.0mm) | - |
|
|
DT200Z-8AC/DC DESKTOP ADAPTER 15V 180W |
0 |
|
规格书 |
DT200Z (200W) | Box | Active | International | Desktop (Class I) | Cord (Sold Separately) | 90 ~ 264 VAC | 15V | 12A | 180 W | 500mW (Max) | - | ITE (Commercial) | 87% | -20°C ~ 60°C | Rectangular, 6 Position | 72" (1.83m) | IEC 320-C14 | - | 8.27" L x 4.06" W x 2.05" H (210.0mm x 103.0mm x 52.0mm) | - |
|
SDI200G-12-UD2-P51AC/DC DESKTOP ADAPTER 12V 192W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 12V | 16A | 192 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 47.2" (1.20m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
SDI200G-56-UC-P51AC/DC DESKTOP ADAPTER 56V 202W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 56V | 3.6A | 202 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-24-U2-P51AC/DC DESKTOP ADAPTER 24V 199W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 24V | 8.3A | 199 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-24-UC-P51AC/DC DESKTOP ADAPTER 24V 199W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 24V | 8.3A | 199 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-48-U2-P51AC/DC DESKTOP ADAPTER 48V 202W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 48V | 4.2A | 202 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-19.5-UD-P51AC/DC DESKTOP ADAPTER 19.5V 199W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord (Sold Separately) | 100 ~ 240 VAC | 19.5V | 10.2A | 199 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-19-UDC-P51AC/DC DESKTOP ADAPTER 19V 200W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 19V | 10.5A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-56-UD2-P51AC/DC DESKTOP ADAPTER 56V 202W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 56V | 3.6A | 202 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-18-UC-P51AC/DC DESKTOP ADAPTER 18V 200W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 18V | 11.1A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-56-UDC-P51AC/DC DESKTOP ADAPTER 56V 202W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 56V | 3.6A | 202 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-19.5-U2-P51AC/DC DESKTOP ADAPTER 19.5V 200W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 19.5V | 10.2A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-20-UDC-P51AC/DC DESKTOP ADAPTER 20V 200W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 20V | 10A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-20-UC-P51AC/DC DESKTOP ADAPTER 20V 200W |
0 |
|
规格书 |
GaN, SDI200G-U (200W) | Box | Active | International | Desktop (Class I) | Cord | 100 ~ 240 VAC | 20V | 10A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C14 | - | 6.34" L x 2.13" W x 1.31" H (161.0mm x 54.2mm x 33.2mm) | EN, FCC, PSE, UL |
|
|
SDI200G-19-UD-P51AC/DC DESKTOP ADAPTER 19V 200W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord (Sold Separately) | 100 ~ 240 VAC | 19V | 10.5A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-12-UDC-P51AC/DC DESKTOP ADAPTER 12V 192W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 12V | 16A | 192 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 47.2" (1.20m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-20-UD2-P51AC/DC DESKTOP ADAPTER 20V 200W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 20V | 10A | 200 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
|
|
SDI200G-24-UD2-P51AC/DC DESKTOP ADAPTER 24V 199W |
0 |
|
规格书 |
GaN, SDI200G-UD (200W) | Box | Active | International | Desktop (Class II) | Cord | 100 ~ 240 VAC | 24V | 8.3A | 199 W | 210mW (Max) | - | ITE (Commercial) | Level VI | 0°C ~ 40°C | Power DIN, 4 Pin | 59" (1.50m) | IEC 320-C8 | - | 5.91" L x 2.13" W x 1.30" H (150.0mm x 54.0mm x 33.0mm) | EN, FCC, PSE, UL |
