图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率(瓦特) | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
1011440CHGRN-200-2001 CH Integrated Power Designs |
50 |
|
- |
GRN-200 (200W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 5V | 25V | - | - | - | - | 30 A | 3 A | - | - | - | - | 225W | ITE (Commercial), Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.14" W x 1.65" H (127.0mm x 79.9mm x 41.9mm) |
![]() |
1011442CHGRN-200-2003 CH Integrated Power Designs |
50 |
|
- |
GRN-200 (200W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 12V | -12V | - | - | - | - | 12 A | 6 A | - | - | - | - | 216W | ITE (Commercial), Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.14" W x 1.65" H (127.0mm x 79.9mm x 41.9mm) |
![]() |
1011443CHGRN-200-2004 CH Integrated Power Designs |
50 |
|
- |
GRN-200 (200W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 10 A | 5 A | - | - | - | - | 225W | ITE (Commercial), Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.14" W x 1.65" H (127.0mm x 79.9mm x 41.9mm) |
![]() |
1011441CHGRN-200-2002 CH Integrated Power Designs |
50 |
|
- |
GRN-200 (200W) | Box | Active | Chassis | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 30 A | 6 A | - | - | - | - | 222W | ITE (Commercial), Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.14" W x 1.65" H (127.0mm x 79.9mm x 41.9mm) |
![]() |
1011497GRN-200-2003-PF Integrated Power Designs |
50 |
|
![]() 规格书 |
GRN-200 (200W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 12V | -12V | - | - | - | - | 12 A | 6 A | - | - | - | - | 200W | Industrial, ITE (Commercial), Laboratory, Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.18" H (127.0mm x 76.2mm x 30.0mm) |
![]() |
1011496GRN-200-2002-PF Integrated Power Designs |
50 |
|
![]() 规格书 |
GRN-200 (200W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 30 A | 6 A | - | - | - | - | 200W | Industrial, ITE (Commercial), Laboratory, Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.18" H (127.0mm x 76.2mm x 30.0mm) |
![]() |
1010902CHNXT-175-1001,LS CH Integrated Power Designs |
50 |
|
![]() 规格书 |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 2.5V | - | - | - | - | - | 35 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) |
![]() |
1010903CHNXT-175-1002,LS CH Integrated Power Designs |
50 |
|
![]() 规格书 |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 35 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) |
![]() |
1010906CHNXT-175-1005,LS CH Integrated Power Designs |
50 |
|
![]() 规格书 |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 11.7 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) |
![]() |
1010904CHNXT-175-1003,LS CH Integrated Power Designs |
50 |
|
![]() 规格书 |
NXT-175 (175W) | Box | Active | Chassis | 1 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 35 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.24" L x 3.12" W x 1.53" H (133.1mm x 79.2mm x 38.9mm) |
